Reference Guide                                                         Fire Strategy



                   •   On operation of a manual door release mechanism.


                   1.5.13  Portable Firefighting Equipment


               Portable firefighting equipment including portable fire extinguishers are not required to
               satisfy the Building Regulations however are required to comply with duties under the
               RR(FS)O. Portable fire extinguishers should the sited in accordance with BS 5306-8.


                   1.5.14  Internal Fire Spread (Linings)


               Internal linings shall be classified as per the table below;

                         Location          National Class    European Class
                                                                             Eg.
                                                                              Brickwork, Blockwork, Plaster finishes (With
                      Small room <30m2          3              D-s3, d2
                                                                              or without water based paint), Ceramic tiles
                                                                              As above. Timber, Hardboard, Blockboard,
                        Other rooms             1               C-s3, d2        Heavy flock wallpapers, thermosetting
                                                                                 plastics, if flame retardant treated
                                                                               As above if not flame retardant treated.
                    Other circulation spaces    0               B-s3, d2
                                                                                     Plywood and Polyesters


                   1.5.15  B3 – Internal Fire Spread Structure


               The fire resistance levels in the following sections are specified in terms of R/E/I, where R, E
               and I correspond to the following and are measured in minutes:


               R – Loadbearing Capacity,
               E – Integrity, and

               I – Insulation.

               Fire resistance requirements shall satisfy either BS 476 or the relevant European Standard
               (i.e. BS EN 1364, 1365 or 1365).

                   1.5.16  Partition Wall


               Approved Document B states that different buildings, or parts of buildings, that are classified

               as different Purpose Groups must be separated by fire resisting construction.

               Where storage is provided in a building designated as Shop and Commercial use, the
               storage area should be separated from the retail area by fire 60 minute resisting construction

               only when the following apply:

                   •   The building or compartment is greater than 280m2 in area, and







              Document Classification     Final    Document Ref:   3.1-RCS-RHSE-(110)-262   Version   1.1
