Page 10 - food store model (single storey)

Reference Guide Fire Strategy

• There are no more than three storeys above the ground storey, and

• The stairs are separated from each occupancy by protected lobbies at all levels.

Where residential flats are situated above a ground floor Co-op store, the egress from above

may only enter into a space shared by the Co-op where the points above are satisfied. Any
common areas should be separated from the front-of-house tenancy by not less than
60/60/60 fire resisting construction (see Internal Fire Spread section below).

1.5.10 Security Locking Mechanisms

Where a door required for means of escape is provided with an electromechanical or
electromagnetic type security device, the device should be appropriately interfaced with the
storewide fire alarm and detection system. The door should fail safe open unlocked in the

following circumstances:

• On operation of the fire alarm system,

• Loss of power or system error, or

• On operation of a manual door release mechanism compliant with BS EN 54-11.

Note: If means of escape is required in both directions a manual door release mechanism
will be required on both sides on the door.

1.5.11 Final Exits

Final exit doors should be easily and immediately openable in a single action from the inside
without the use of a key. Where electrically operated doors are installed, the provisions of
the following section also apply.

Where a system exists for the securing of properties out of hours by the use of external
security, grills, gates or shutters, a robust management procedure must be introduced to
ensure that these securing devices are fully removed and secured in the open position whilst

the building is in use.

1.5.12 Electrically Powered Doors

Electrically powered doors, such as main entrance sliding doors, shall be interfaced with the
storewide fire alarm and detection system to fail safe open in the following circumstances:

• On operation of the fire alarm system,

• Loss of power or system error, or
