Page 32 - 2020 October Lighting Catalog

Flood lighting

LED Small Floods

Cat. Old Watts volts mount Housing Color Replaces Dimensions Weight Case
(Inches)
Metal
No. Color Temp Lumens Halide H W D (lbs) Qty Each
71531A 71531 15W 120-277v Yoke Bronze 5000K 1,663 70W 3-1/4 4-5/8 1-1/2 1.5 16
71801A - 15W 120-277v Yoke White 5000K 1,624 70W 4-5/8 4-3/4 1-1/2 1.5 16
71551A - 15W 120-277v 1/2” knuckle Bronze 5000K 1,624 70W 5-3/8 4-3/8 1-1/2 1.5 16
71821A - 15W 120-277v 1/2” knuckle White 5000K 1,624 70W 5-3/8 4-3/8 1-1/2 1.5 16
74073A - 15W 120-277v Yoke Bronze 4000K 1,603 70W 4-5/8 4-3/4 1-1/2 1.5 16
YOKE BRACKET Mount 74076A - 15W 120-277v 1/2” knuckle Bronze 4000K 1,603 70W 5-3/8 4-3/8 1-1/2 1.5 16
Fixture Includes Mount 71802A - 15W 120-277v Yoke Bronze 3000K 1,593 70W 4-5/8 4-3/4 1-1/2 1.5 16
71803A - 15W 120-277v Yoke White 3000K 1,593 70W 4-5/8 4-3/4 1-1/2 1.5 16
71552A - 15W 120-277v 1/2” knuckle Bronze 3000K 1,593 70W 5-3/8 4-3/8 1-1/2 1.5 16
71553A 71553 15W 120-277v 1/2” knuckle White 3000K 1,566 70W 4-3/8 3-1/4 1-1/2 1.5 16
71532A - 30W 120-277v Yoke Bronze 5000K 3,432 100W 7 7-1/4 1-3/4 3.5 8
71804 - 30W 120-277v Yoke White 5000K 3,432 100W 7 7-1/4 1-3/4 3.5 8
71554A - 30W 120-277v 1/2” knuckle Bronze 5000K 3,432 100W 9-1/8 7-1/8 1-7/8 3.5 8
71822A - 30W 120-277v 1/2” knuckle White 5000K 3,432 100W 9-1/8 7-1/8 1-7/8 3.5 8
74074A - 30W 120-277v Yoke Bronze 4000K 3427 100W 7 7-1/4 1-3/4 3.5 8
74077A - 30W 120-277v 1/2” knuckle Bronze 4000K 3,427 100W 9-1/8 7-1/8 1-7/8 3.5 8
71805A - 30W 120-277v Yoke Bronze 3000K 3,404 100W 7 7-1/4 1-3/4 3.5 8
71806A - 30W 120-277v Yoke White 3000K 3,404 100W 7 7-1/4 1-3/4 3.5 8
71555A - 30W 120-277v 1/2” knuckle Bronze 3000K 3,404 100W 9-1/8 7-1/8 1-7/8 3.5 8
White
7-1/8
1/2” Knuckle Mount 71556A - - 30W 120-277v 1/2” knuckle Bronze 3000K 3,404 100W 9-1/8 8-1/2 1-7/8 3.5 8 6
150W
7-7/8
5
50W
120-277v
Yoke
5,793
5000K
1-7/8
71533A
Fixture Includes Mount 71807A - 50W 120-277v Yoke White 5000K 5,793 150W 7-7/8 8-1/2 1-7/8 5 6
71557A - 50W 120-277v 1/2” knuckle Bronze 5000K 5,793 150W 10-1/8 8-1/2 2-1/8 5 6
71823A - 50W 120-277v 1/2” knuckle White 5000K 5,793 150W 10-1/8 8-1/2 2-1/8 5 6
74075A - 50W 120-277v Yoke Bronze 4000K 5,778 150W 7-7/8 8-1/2 1-7/8 5 6
74078A - 50W 120-277v 1/2” knuckle Bronze 4000K 5,778 150W 10-1/8 8-1/2 2-1/8 5 6
71808A - 50W 120-277v Yoke Bronze 3000K 5,717 150W 7-7/8 8-1/2 1-7/8 5 6
71809A - 50W 120-277v Yoke White 3000K 5,717 150W 7-7/8 8-1/2 1-7/8 5 6
71824A - 50W 120-277v 1/2” knuckle Bronze 3000K 5,717 150W 10-1/8 8-1/2 2-1/8 5 6
71825A - 50W 120-277v 1/2” knuckle White 3000K 5,717 150W 10-1/8 8-1/2 2-1/8 5 6
LED Dimmable Small Floods
(Inches)
Cat. Watts volts MOUNT Housing Color Lumens Replaces Dimensions Case Each
Metal
No. Color Temp Halide H W D Qty
1/2” Knuckle 30 WATTS
71826 30W 120-277v BRACKET Bronze 5000K 3,530 100W 4-5/8 4-1/2 1-1/2 10
71827 30W 120-277v 1/2” KNUCKLE Bronze 5000K 3,530 100W 4-5/8 4-1/2 1-1/2 10
50 WATTS
71828 50W 120-277v BRACKET Bronze 5000K 6,005 150W 7-1/2 8/3/4 1-3/4 6
71829 50W 120-277v 1/2” KNUCKLE Bronze 5000K 6,005 150W 7-1/2 8/3/4 1-3/4 6
bracket
economy/temp Floodlight

10W 20W 30W 50W 100W

Cat. Watts Delivered volts housing Color CRI lumens/ Case Each
No. Lumens color Temp watt Qty
74200 10W 1,000 90-277v Black 5700K 80 100W 20
floor and table 74201 20W 2,000 90-277v Black 5700K 80 100W 20
displays available 74202 30W 3,000 90-277v Black 5700K 80 100W 20
10
100W
80
5,000
90-277v
74203
50W
5700K
Black
upon request 74204 100W 10,000 90-277v Black 5700K 80 100W 10
Yoke Bracket and Power Cord with Three Prong Plug on all fixtures
