Page 29 - 2020 October Lighting Catalog

AREA LIGHTing

Area-Light Gen 3
Dimmable
1-10V
Cat. Light Color Housing Replaces Weight Case
Metal
No. Fig Pattern Watts Volts Temp Color Lumens LM/w Halide (lbs) Qty Each
Type III, IV & V Light Pattern (Fixture Only - Order Mounts Separately)
80 Watts
74079A 1 III 80W 120-277V 5000K Bronze 10,544 132 175W 13 1 t3, t4, t5 distributions
74046A 1 III 80W 120-277V 5000K White 10,544 132 175W 13 1 motion sensor available
74047A 1 III 80W 120-277V 4000K Bronze 10,497 131 175W 13 1
74080A 1 IV 80W 120-277V 5000K Bronze 10,592 132 175W 13 1 glare sheild available
74045A 1 V 80W 120-277V 5000K Bronze 10,491 131 175W 13 1 2 pc mounting design
100 WATTS
74002A 1 III 100W 120-277V 5000K Bronze 13,077 131 250W 13 1
74004A 1 III 100W 120-277V 5000K White 13,077 131 250W 13 1
74000A 1 III 100W 120-277V 4000K Bronze 12,917 129 250W 13 1
74048A 1 III 100W 347-480V 5000K Bronze 13,329 133 250W 13 1
74003A 1 IV 100W 120-277V 5000K Bronze 12,998 130 250W 13 1
74005A 1 IV 100W 120-277V 5000K White 12,998 130 250W 13 1
74001A 1 IV 100W 120-277V 4000K Bronze 12,835 128 250W 13 1
74049A 1 IV 100W 347-480V 5000K Bronze 12,979 130 250W 13 1
74050A 1 V 100W 120-277V 5000K Bronze 12,693 127 250W 13 1
74052A 1 V 100W 120-277V 4000K Bronze 12,533 125 250W 13 1
74051A 1 V 100W 347-480V 5000K Bronze 12,822 128 250W 13 1 Fig. 1
150 WATTS
74010A 1 III 150W 120-277V 5000K Bronze 19,186 128 400W 14 1
74012A 1 III 150W 120-277V 5000K White 19,186 128 400W 14 1
74008A 1 III 150W 120-277V 4000K Bronze 18,931 126 400W 14 1
74014A 1 III 150W 347-480V 5000K Bronze 19,275 128 400W 14 1
74011A 1 IV 150W 120-277V 5000K Bronze 19,367 129 400W 14 1
74013A 1 IV 150W 120-277V 5000K White 19,367 129 400W 14 1
74009A 1 IV 150W 120-277V 4000K Bronze 19,139 129 400W 14 1
74015A 1 IV 150W 347-480V 5000K Bronze 18,694 125 400W 14 1
74053A 1 V 150W 120-277V 5000K Bronze 19,142 129 400W 14 1
74055A 1 V 150W 120-277V 4000K Bronze 18,907 126 400W 14 1
74054A 1 V 150W 347-480V 5000K Bronze 18,668 125 400W 14 1
200 Watts
74056A 2 III 200W 120-277V 5000k Bronze 26,199 131 600W 18 1
74057A 2 III 200W 347-480V 5000K Bronze 26,143 131 600W 18 1
74062A 2 III 200W 120-277V 5000K White 26,199 131 600W 18 1
74063A 2 III 200W 120-277V 4000K Bronze 25,846 129 600W 18 1
74081A 2 III 200W 347-480V 4000K Bronze 25,816 129 600W 18 1
74058A 2 IV 200W 120-277V 5000K Bronze 25,843 129 600W 18 1
74059A 2 IV 200W 347-480V 5000K Bronze 26,063 130 600W 18 1
74064A 2 IV 200W 120-277V 4000K Bronze 25,552 128 600W 18 1
74060A 2 V 200W 120-277V 5000K Bronze 26,143 131 600W 18 1 Fig. 2
74061A 2 V 200W 347-480V 5000K Bronze 25,483 127 600W 18 1
74065A 2 V 200W 120-277V 4000K Bronze 25,833 129 600W 18 1
240 Watts
74018A 2 III 240W 120-277V 5000K Bronze 31,989 133 750W 19 1
74022A 2 III 240W 347-480V 5000K Bronze 30,734 128 750W 19 1
74020A 2 III 240W 120-277V 5000K White 31,989 133 750W 19 1
74016A 2 III 240W 120-277V 4000K Bronze 31,678 132 750W 19 1
74019A 2 IV 240W 120-277V 5000K Bronze 31,678 132 750W 19 1
74023A 2 IV 240W 347-480V 5000K Bronze 30,508 128 750W 19 1
74021A 2 IV 240W 120-277V 5000K White 31,678 132 750W 19 1
74017A 2 IV 240W 120-277V 4000K Bronze 31,371 131 750W 19 1
74066A 2 V 240W 120-277V 5000K Bronze 31,963 132 750W 19 1
74067A 2 V 240W 347-480V 5000K Bronze 30,706 128 750W 19 1
74068A 2 V 240W 120-277V 4000k Bronze 31,479 131 750W 19 1
300 Watts
74026A 2 III 300W 120-277V 5000K Bronze 39,827 133 1000W 20 1
74030A 2 III 300W 347-480V 5000K Bronze 40,356 134 1000W 20 1
74028A 2 III 300W 120-277V 5000K White 39,827 133 1000W 20 1
74024A 2 III 300W 120-277V 4000K Bronze 39,391 131 1000W 20 1
74027A 2 IV 300W 120-277V 5000K Bronze 39,836 133 1000W 20 1
74031A 2 IV 300W 347-480V 5000K Bronze 39,844 133 1000W 20 1
74029A 2 IV 300W 120-277V 5000K White 39,836 133 1000W 20 1
74025A 2 IV 300W 120-277V 4000K Bronze 39,470 132 1000W 20 1
74069A 2 V 300W 120-277V 5000K Bronze 37,811 126 1000W 20 1
74070A 2 V 300W 347-480V 5000K Bronze 39,429 131 1000W 20 1
74071A 2 V 300W 120-277V 4000K Bronze 37,332 125 1000W 20 1

Please review online specification sheets. Pictures and certifications may not be 100% representative of the product listed.
To view details of our DLC qualified products, please consult the DLC Qualified Products List at www.designlights.org/qpl
FOR MORE INFO SEE THE 2019 LIGHTING Catalog and or visit morrisproducts.com 27
