33-14
Transmission axle-universal joint

(c). Install the retainer ring with circlip pliers.
• A new retainer ring must be replaced
with.

(d). Install the grease nipple.
• A new grease nipple must be replaced
with.

7. Install the transmission axle universal joint of rear axle

Hint:
The steps for the assembly of the transmission universal joint of rear axle are the same with those for
the universal joint of sliding yoke.

8. Assemble the universal joint of the intermediate transmission axle
HINT:
The steps for the assembly of the universal joint of intermediate transmission axle are the same with
those for the universal joint of sliding yoke.

33 9. Install the transmission axle (refer to “chapter 33 transmission axle-transmission axle
assembly, replacement”)
