51-14
Heater and air conditioner-air duct of instrument panel
6. Remove the middle air duct
(a). Loosen the 4 bolts and remove the middle
air duct.
7. Remove the right air duct
(a). Loosen the bolts and remove the right air
duct.
8. Install the left defrost air duct
(a). Screw down the bolt and install the left
defrost air duct.
51 9. Install the middle defrost air duct
(a). Screw down the bolt and install the middle
defrost air duct.
10. Install the right defrost air duct
(a). Screw down the 2 bolts and install the
right defrost air duct.
