61-20
Circuit-System circuit diagram

Service hint

· B026 Ignition switch

1-3: it is connected when the ignition switch is at ON or ST.

1-2: it is connected when the ignition switch is at ST.

· R1 starting relay

1-4: the contacts will be closed when the ignition switch is at ST.

: part position-12

Reference wire Reference wire Reference wire
S/N S/N S/N
harness harness harness
B026 Body wire C008 Body wire C051 Chassis wire
B050 Body wire C009 Body wire

: insert parts among wire harnesses-13
S/N S/N Reference wire harness (position of the insert parts)
B103 C101 Body wire and chassis wire (middle of the first cross member of frame)
B105 C105 Body wire and chassis wire (middle of the first cross member of frame)

: grounding-14

S/N Grounding position
B237 The chassis wire is grounded
B238 The chassis wire is grounded
