77-24
Internal/external trimming parts-carpet

Replacement

1. Remove the driver seat (Refer to “Chapter 74 Seat-Driver Seat, Replacement”)
2. Remove the co-driver seat (Refer to “Chapter 74 Seat-Co-driver Seat, Replacement”)
3. Remove the sleeper device (Refer to “Chapter 74 Seat-Sleeper Device, Replacement”)
4. Remove the parking brake handle (Refer to “Chapter 27 Parking Brake-Parking
Brake Handle, Replacement”)
5. Remove the parking hand brake valve (Refer to “Chapter 27 Parking Brake-Handle
Brake Valve, Replacement”)
6. Remove the transmission control shield (Refer to “Chapter 77 Internal/External
Trimming Parts-Transmission Control Shield, Replacement”)
7. Remove the steering column assembly (Refer to “Chapter 41 Steering
Mechanism-Steering Column Assembly, Overhaul”)
8. Remove the steering support (Refer to “Chapter 41 Steering Mechanism-Steering
Support, Replacement”)
77 9. Remove the pedal suspension
(a). Remove the 2 fixing nuts of the pedal
suspension and the driving cab.

10. Remove the sealing strip of the left
door
(a). Remove the 4 fixing screws of the
sealing strip trim strip of the left door.
