04-368
Diagnosis-Power Windows

(c) Disconnect the parking brake indicator
light switch connector at the bottom of
parking brake control handle assembly.

4

(d) Ignition switch: ON.
Check if parking brake indicator light goes out.
Yes > Replace parking brake control handle assembly.
No > Go to step 2.
2. Checking for parking brake indicator light signal circuit short
(a) Ignition switch: OFF.
(b) Disconnect connector of combination
meter B034.

(c) Use a multimeter to measure resistance
to ground of connector pin 1 of parking
brake indicator light switch L002.
Resistance: >1MΩ

Is check result normal?
Yes > Replace combination meter assembly.
No > Repair signal line to ground short between connector pin 1 of parking brake indicator light
switch L002 and connector pin 11 of combination meter B034.
