25-33
Rear axle- Differential assembly
11. Assemble the differential assembly
(a). Install the left half-axle gear and the half-axle
gear thrust washer.
(b). Install the planetary gear and the cross shaft
assembly (including the planetary gear thrust
washer).
(c). Install the right half-axle gear and the half-axle
gear thrust washer.
25
(d). Screw down the 2 bolts on the cross and connect
the left and right housing of the differential.
Notice:
Make sure that the installation is carried out in
accordance with the matchmarks.
Hint:
It is no need to screw down all the bolts at this step,
only a group of bolts on any diagonal line is enough.
