Silentblocs and Bushings

KL-0039-160 K
KL-0039-160 K
Pressure/Support Sleeve Set,
Ø 30-90mm, short, 45mm, in a Plastic Storage Case

Indispensable tool set for pressing in and pressing out silentblocs, shafts, bushings
etc. The sleeves are used in conjunction with the tools of the KL-0039-.. Series.
Scope of Delivery: KL-0039-160 K Pressure/Support Sleeve Set, Ø 30-90mm,
short, 45mm, in a Plastic Storage Case
Part No. Description Qty
KL-0039-160 E Pressure/Support Sleeve Set, Ø 30-90mm (short) 45mm 1
KL-4999-1391 Plastic Storage Case 1
Scope of Delivery: KL-0039-160 E Pressure/Support Sleeve Set, Ø 30-90mm,
short, 45mm, in a Foam Insert
Part No. Description Qty
KL-0039-160 Press-/Support Sleeve Set, Ø 30-90mm (short), 45mm 1
KL-0039-160 E KL-4999-1312 Foam Insert 1
Scope of Delivery:
KL-0039-160 Pressure/Support Sleeve Set, Ø 30-90mm, short, 45mm
Part No. Description Qty Part No. Description Qty Part No. Description Qty
4 KL-0039-1630 Pressure-/Support Sleeve, short, Ø30/22mm 1 1 KL-0039-1652 Pressure-/Support Sleeve, short, Ø52/44mm 1 1 KL-0039-1672 Pressure-/Support Sleeve, short, Ø72/64mm 1 1
KL-0039-1674 Pressure-/Support Sleeve, short, Ø74/66mm
KL-0039-1654 Pressure-/Support Sleeve, short, Ø54/46mm
KL-0039-1632 Pressure-/Support Sleeve, short, Ø32/24mm
KL-0039-1634 Pressure-/Support Sleeve, short, Ø34/26mm 1 KL-0039-1656 Pressure-/Support Sleeve, short, Ø56/48mm 1 KL-0039-1676 Pressure-/Support Sleeve, short, Ø76/68mm 1
KL-0039-1636 Pressure-/Support Sleeve, short, Ø36/28mm 1 KL-0039-1658 Pressure-/Support Sleeve, short, Ø58/50mm 1 KL-0039-1678 Pressure-/Support Sleeve, short, Ø78/70mm 1
KL-0039-1638 Pressure-/Support Sleeve, short, Ø38/30mm 1 KL-0039-1660 Pressure-/Support Sleeve, short, Ø60/52mm 1 KL-0039-1680 Pressure-/Support Sleeve, short, Ø80/72mm 1
KL-0039-1640 Pressure-/Support Sleeve, short, Ø40/32mm 1 KL-0039-1662 Pressure-/Support Sleeve, short, Ø62/54mm 1 KL-0039-1682 Pressure-/Support Sleeve, short, Ø82/74mm 1
KL-0039-1642 Pressure-/Support Sleeve, short, Ø42/34mm 1 KL-0039-1664 Pressure-/Support Sleeve, short, Ø64/56mm 1 KL-0039-1684 Pressure-/Support Sleeve, short, Ø84/76mm 1
KL-0039-1644 Pressure-/Support Sleeve, short, Ø44/36mm 1 KL-0039-1666 Pressure-/Support Sleeve, short, Ø66/58mm 1 KL-0039-1686 Pressure-/Support Sleeve, short, Ø86/78mm 1
KL-0039-1646 Pressure-/Support Sleeve, short, Ø46/38mm 1 KL-0039-1668 Pressure-/Support Sleeve, short, Ø68/60mm 1 KL-0039-1688 Pressure-/Support Sleeve, short ,Ø88/80mm 1
KL-0039-1648 Pressure-/Support Sleeve, short, Ø48/40mm 1 KL-0039-1670 Pressure-/Support Sleeve, short, Ø70/62mm 1 KL-0039-1690 Pressure-/Support Sleeve, short, Ø90/82mm 1
KL-0039-1650 Pressure-/Support Sleeve, short, Ø50/42mm 1
KL-0039-170 K
KL-0039-170 K
Pressure/Support Sleeve Set,

Ø 30-90mm, long, 115mm, in a Plastic Storage Case
Indispensable tool set for pressing in and pressing out silentblocs, shafts, bushings
etc. The sleeves are used in conjunction with the tools of the KL-0039-.. Series.
Scope of Delivery: KL-0039-170 K Pressure/Support Sleeve Set, Ø 30-90mm,
long, 115mm, in a Plastic Storage Case
Part No. Description Qty
KL-0039-170 E Pressure/Support Sleeve Set, Ø 30-90mm, long, 115mm 1
KL-4999-1390 Plastic Storage Case 1
Scope of Delivery: KL-0039-170 E Pressure/Support Sleeve Set, Ø 30-90mm,
long, 115mm, in a Foam Insert
Part No. Description Qty
KL-0039-170 Pressure/Support Sleeve Set Ø 30-90mm, long, 115mm 1
KL-0039-170 E KL-4999-1311 Foam Insert 1
Scope of Delivery: KL-0039-170 Pressure/Support Sleeve Set, Ø 30-90mm, long, 115mm
Part No. Description Qty Part No. Description Qty Part No. Description Qty
KL-0039-1730 Pressure-/Support Sleeve, long, Ø 30/22mm 1 KL-0039-1752 Pressure-/Support Sleeve, long, Ø 52/44mm 1 KL-0039-1772 Pressure-/Support Sleeve, long, Ø 72/64mm 1
KL-0039-1732 Pressure-/Support Sleeve, long, Ø 32/24mm 1 KL-0039-1754 Pressure-/Support Sleeve, long, Ø 54/46mm 1 KL-0039-1774 Pressure-/Support Sleeve, long, Ø 74/66mm 1
KL-0039-1734 Pressure-/Support Sleeve, long, Ø 34/26mm 1 KL-0039-1756 Pressure-/Support Sleeve, long, Ø 56/48mm 1 KL-0039-1776 Pressure-/Support Sleeve, long, Ø 76/68mm 1
KL-0039-1736 Pressure-/Support Sleeve, long, Ø 36/28mm 1 KL-0039-1758 Pressure-/Support Sleeve, long, Ø 58/50mm 1 KL-0039-1778 Pressure-/Support Sleeve, long, Ø 78/70mm 1
KL-0039-1738 Pressure-/Support Sleeve, long, Ø 38/30mm 1 KL-0039-1760 Pressure-/Support Sleeve, long, Ø 60/52mm 1 KL-0039-1780 Pressure-/Support Sleeve, long, Ø 80/72mm 1
KL-0039-1740 Pressure-/Support Sleeve, long, Ø 40/32mm 1 KL-0039-1762 Pressure-/Support Sleeve, long, Ø 62/54mm 1 KL-0039-1782 Pressure-/Support Sleeve, long, Ø 82/74mm 1
KL-0039-1742 Pressure-/Support Sleeve, long, Ø 42/34mm 1 KL-0039-1764 Pressure-/Support Sleeve, long, Ø 64/56mm 1 KL-0039-1784 Pressure-/Support Sleeve, long, Ø 84/76mm 1
KL-0039-1744 Pressure-/Support Sleeve, long, Ø 44/36mm 1 KL-0039-1766 Pressure-/Support Sleeve, long, Ø 66/58mm 1 KL-0039-1786 Pressure-/Support Sleeve, long, Ø 86/78mm 1
KL-0039-1746 Pressure-/Support Sleeve, long, Ø 46/38mm 1 KL-0039-1768 Pressure-/Support Sleeve, long, Ø 68/60mm 1 KL-0039-1788 Pressure-/Support Sleeve, long, Ø 88/80mm 1
KL-0039-1748 Pressure-/Support Sleeve, long, Ø 48/40mm 1 KL-0039-1770 Pressure-/Support Sleeve, long, Ø 70/62mm 1 KL-0039-1790 Pressure-/Support Sleeve, long, Ø 90/82mm 1
KL-0039-1750 Pressure-/Support Sleeve, long, Ø 50/42mm 1
