1300 527 668 KARMOT PTY LTD

SVP410117K TWIN 13.8 Roller Brake Tester Kit

Features
 The test stand is equipped with attachable wheels and can
easily be moved on site after folding up or removing the ramps. With its low weight of
1,100 kg (without ramps), the test bench can also be loaded with a transport vehicle and
transported to other locations. The axle shafts of the removable wheels serve as Eyelets for
the hoist. When setting up on uneven ground, the test bench can be compensated with the
height-adjustable outriggers .
 The rollers are granulate-coated and have a roller diameter of 150mm.
 All Sherpa dynamometers are equipped with the same electrical and instrumentation
technology. Therefore, the displays and options of the entire BPS test bench range can also
be used on the mobile test bench.
 After connecting the supply voltage to the test bench and one of the displays to the
electrical / switch box, the test stand is ready for use immediately.
 Test bench control: manual / automatic mode, delayed automatic switch-on, slip shut-off,
pointer stop, automatic restart, switch-off after exiting the test bench, start-up monitoring
and extension aid.
 Wear-free, electronic strain
PORTABLE ROLLER BRAKE TESTER
gauge measuring system with
shear force transducer.
 Australian models sold with
NHVR compliant software.
 Full operation of RBT from in
cabin via tablet.
 Comprehensive how the system
works instructional brochure for
on going reference.
 EDOS Easy Drive Out System.
Mobile RBT Technical data
Size of each roller beds – one piece (L x W x H) 4650mm x 1360mm x 150mm
Diameter of rollers 150mm
Standard length of rollers 1000m
Maximum axle test weight 18000kg
Gear motor size 11kW x 2
Test speed 2.6km/h
Maximum brake force measurement 4,000 kgf
Power requirement 3 phase (L+N+E) 50a Isolator with commando socket
Tablet Operated Yes

SVP410015K + SVP230006K MOBILE RBT / AST Kit

Features
 Mobile Roller Brake Tester with the addition of the AST play detector
