KARMOT PTY LTD 1300 527 668

SVP420015K Side Slip Tester

 Fast and easy to use, by just driving over the plate.

 The tension- release- plate eliminates tensions in the chassis and gives a much more reliable and consistent
reading (only required for car testing).
 Track measurements and tolerances are indicated in mm/m on the display unit.
 The galvanised side slip plates have a grip surface construction and a reliable ball bearing guidance system.

 A electronic controller sends the results to a easy to read digital display.
 No foundation required. Easy surface mounting, only 50mm above ground, or easy foundation mounting, easy
installation, 240 / 110 V power required.
Scope of supply standalone unit:
 Display unit with electronic controller and high power LED'S.
 1 galvanised side slip plate- plate with tear- drop surface.

 1 tension- release- plate (only for SSP-400 and SSP- 600).
 17 m cable with plug.
Scope of supply of track plate for retrofitting to “Sherlane”:
 1 galvanised side slip plate with tear-drop-surface.
 1 tension- release- plate.

 17 m cable with plug. Side Slip Tester

Test plate with Tension release
plate for SSP400 and SSP600. LED display for stand alone Test plate without Tension
unit SSP400 to SSP1500. release plate for SSP-1500.

Side Slip Tester Technical Data

Galvanised test plates with Tear drop steel
Low maintenance bearings Low-wear bearings m

Maintenance free measurement system Electronically measurement
Power supply DC 12 V

Dimensions side slip plate SSP-1.500 (L x W x H) 750 x 990 x 50 mm
Weight SSP-1.500 90 kg

sales@karmot.com www.karmot.com Page 43
