National Electrical Price Guide

Assemblies
Recept 20A Standard On Metal Stud with Plastic Plate Single Ivory
Qty Description Labor Cost Retail
3 #16-#10 Red Wire Nut .00 .39 .66
1 Tap-on Box to Stud Clip .02 .84 1.28
1 Single Ivy 20A 125V Spec Recpt .20 3.40 13.11
1 1G Sgl Recp Smooth Nylon Ivy Plate .06 .33 1.20
1 1/2"&3/4" KO 4"x1-1/2" Sq Drawn Box .10 .71 6.90
1 5/8" Rise 4" Sq 1G Device Ring .05 .49 4.50
1 6" #12 Pigtail .02 .28 2.35
.45 $6.44 $30.00
On Metal Stud with St Steel Plate
Recept 20A Standard On Metal Stud with St Steel Plate Double Duplex Gray

Qty Description Labor Cost Retail
5 #16-#10 Red Wire Nut .00 .65 1.10
1 Tap-on Box to Stud Clip .02 .84 1.28
1 2G Dup Recp 302 St Steel Plate .06 2.22 6.20
2 Duplex Gry 20A 125V Spec Recpt .40 8.54 26.70
2 6" #12 Pigtail .04 .56 4.70
1 1/2"&3/4" KO 4"x1-1/2" Sq Drawn Box .10 .71 6.90
1 5/8" Rise 4" Sq 2G Device Ring .05 .65 5.95
.67 $14.17 $52.83
Recept 20A Standard On Metal Stud with St Steel Plate Duplex Gray
Qty Description Labor Cost Retail
3 #16-#10 Red Wire Nut .00 .39 .66
1 Tap-on Box to Stud Clip .02 .84 1.28
1 Duplex Gry 20A 125V Spec Recpt .20 4.27 13.35
1 1G Dup Recp 302 St Steel Plate .05 1.09 2.85
1 1/2"&3/4" KO 4"x1-1/2" Sq Drawn Box .10 .71 6.90
1 5/8" Rise 4" Sq 1G Device Ring .05 .49 4.50
1 6" #12 Pigtail .02 .28 2.35
.44 $8.07 $31.89
Recept 20A Standard On Metal Stud with St Steel Plate GFI Gray
Qty Description Labor Cost Retail
3 #16-#10 Red Wire Nut .00 .39 .66
1 Tap-on Box to Stud Clip .02 .84 1.28
1 Gry 20A GFI Recpt no Indicator .20 15.61 25.60
1 1G 302 St Steel DECORA Plate .06 1.06 4.90
1 1/2"&3/4" KO 4"x1-1/2" Sq Drawn Box .10 .71 6.90
1 5/8" Rise 4" Sq 1G Device Ring .05 .49 4.50
1 6" #12 Pigtail .02 .28 2.35
.45 $19.38 $46.19
On Standard Box with WP Cover
Recept 20A Standard On Standard Box with WP Cover Duplex Brown

Qty Description Labor Cost Retail
3 #16-#10 Red Wire Nut .00 .39 .66
1 Duplex Brn 20A 125V Spec Recpt .20 4.27 13.35
1 5/8" Rise 4" Sq 1G Device Ring .05 .49 4.50
1 Cast Box Duplex Recpt Cover-1G Vert .06 2.30 9.43
1 1/2"&3/4" KO 4"x1-1/2" Sq Drawn Box .10 .71 6.90
1 6" #12 Pigtail .02 .28 2.35
.43 $8.44 $37.19

ASSEMBLIES CONTAINING CONDUIT ARE BASED ON 10' LENGTHS
COST COLUMN IS A NATIONAL AVERAGE AND SHOULD BE VERIFIED FOR YOUR AREA
COPYRIGHT @ 1996-2019 by ELECTRICAL RESOURCES, INC.
