Tools for threads
Hand screw taps
Version Set Taper tap Second tap Third tap
Lead angle shape A/D/C A D C
13017... 13017... 13017... 13017...
Ident. No. Ident. No. Ident. No. Ident. No.
Metal cutting tools
Metal cutting tools
mm mm mm mm mm
M3 0.5 2.5 40 3.5 2.7 030 O. R. - - - - - -
M4 0.7 3.3 45 4.5 3.4 040 O. R. 734 O. R. 834 O. R. 934 O. R.
M5 0.8 4.2 50 6 4.9 050 O. R. 738 O. R. 838 O. R. 938 O. R.
M6 1 5 50 6 4.9 060 O. R. 740 O. R. 840 O. R. 940 O. R.
M8 1.25 6.8 56 6 4.9 080 O. R. 744 O. R. 844 O. R. 944 O. R.
M10 1.5 8.5 70 7 5.5 100 O. R. - - - - - -
M12 1.75 10.2 75 9 7 120 O. R. - - - - - -
Set price, € Unit price, €
Prod. Gr. 131
Hand tap HSS DIN 2181
for universal use up to 1000 N/mm 2
MF HSS
3xd A (6-8)
Application: No. 13023 703–13023 786: Taper tap with notch
No. 13020 045–13020 360, 13023 803–13023 shape A with one ring No. 13020 045–13023 786
886: For manually tapping fine metric threads in No. 13023 803–13023 886: Third tap notch shape Taper tap, shape D
through holes and blind holes in the steel, NF metal C without ring
and (cast) material groups up to a strength of 1000
N/mm in single part production. Advantage:
2
No. 13023 030–13023 786: For producing metric No. 13020: Long service life and high level of
fine threads by hand in through holes and blind process reliability thanks to innovative cutting
holes, in steel, non-ferrous metals and (cast iron) geometry and universal application for maximum No. 13020 045–13023 280, 13023 803–13023 886
Third tap, shape C
material groups up to a strength of 1000 N/mm in flexibility in use
2
single-part production. No. 13023 030–13023 786: Standard geometry
with very good price/performance ratio
Execution: No. 13023 803–13023 886: Standard geometry
No. 13020: Set consisting of taper tap (form A) with a very good price-performance ratio
and third tap (form C)
No. 13023 030–13023 280: Set containing taper
tap (form A) and third tap (plug) (form C)
Application Steel (N/mm ) 2 Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
13020
13023030-280
13023703-786
13023803-886
Version Set Set Taper tap Third tap
Lead angle shape D/C D/C A A
13023... 13020... 13023... 13023...
Ident. No. Ident. No. Ident. No. Ident. No.
mm mm mm mm mm
MF3 0.35 2.65 40 3.5 2.7 030 O. R. - - - - - -
MF4 0.5 3.5 45 4.5 3.4 045 O. R. 045 O. R. - - - -
MF5 0.5 4.5 50 6 4.9 050 O. R. 050 O. R. - - - -
MF6 0.5 5.5 50 6 4.9 - - 060 O. R. - - - -
MF6 0.75 5.2 50 6 4.9 065 O. R. 065 O. R. - - - -
MF7 0.75 6.2 50 6 4.9 - - 070 O. R. - - - -
MF8 0.5 7.5 50 6 4.9 - - 080 O. R. - - - -
MF8 0.75 7.2 50 6 4.9 083 O. R. 083 O. R. - - - -
MF8 1 7 56 6 4.9 086 O. R. 086 O. R. 786 O. R. 886 O. R.
MF10 1 9 63 7 5.5 103 O. R. 103 O. R. 703 O. R. 803 O. R.
MF10 1.25 8.8 70 7 5.5 106 O. R. 106 O. R. - - - -
MF10 0.75 9.2 68 7 5.5 - - 100 O. R. - - - -
MF12 1 11 70 9 7 120 O. R. 120 O. R. 720 O. R. 820 O. R.
MF12 1.25 10.8 70 9 7 123 O. R. 123 O. R. - - - -
MF12 1.5 10.5 70 9 7 126 O. R. 126 O. R. 726 O. R. 826 O. R.
MF14 1 13 70 11 9 140 O. R. 140 O. R. - - - -
MF14 1.25 12.8 70 11 9 143 O. R. 143 O. R. - - - -
MF14 1.5 12.5 70 11 9 146 O. R. 146 O. R. 742 O. R. 842 O. R.
MF15 1 14 70 12 9 - - 150 O. R. - - - -
MF16 1 15 70 12 9 160 O. R. 160 O. R. - - - -
MF16 1.5 14.5 70 12 9 165 O. R. 165 O. R. 765 O. R. 865 O. R.
MF18 1 17 80 14 11 180 O. R. 180 O. R. 780 O. R. 880 O. R.
MF18 1.5 16.5 80 14 11 183 O. R. 183 O. R. 783 O. R. 883 O. R.
MF20 1 19 80 16 12 200 O. R. 200 O. R. - - - -
MF20 1.5 18.5 80 16 12 203 O. R. 203 O. R. 713 O. R. 813 O. R.
MF20 2 18 80 16 12 206 O. R. - - - - - -
MF22 1.5 20.5 80 18 14.5 223 O. R. 223 O. R. - - - -
MF22 1 21 80 18 14.5 220 O. R. - - - - - -
MF24 1 23 90 18 14.5 - - 240 O. R. - - - -
MF24 1.5 22.5 90 18 14.5 243 O. R. 243 O. R. - - - -
MF24 2 22 90 18 14.5 - - 246 O. R. - - - -
MF26 1.5 24.5 90 18 14.5 260 O. R. - - - - - -
