Tools for threads
Metal cutting tools
Hand screw taps

Version Set Set Taper tap Third tap
Lead angle shape D/C D/C A A
13023... 13020... 13023... 13023...
Ident. No. Ident. No. Ident. No. Ident. No.
mm mm mm mm mm
MF27 2 25 90 20 16 - - 275 O. R. - - - -
MF28 1.5 26.5 90 20 16 280 O. R. - - - - - -
MF30 1.5 28.5 90 22 18 - - 303 O. R. - - - -
MF30 2 28 90 22 18 - - 306 O. R. - - - -
MF36 1.5 34.5 100 28 22 - - 360 O. R. - - - -
Set price, € Unit price, €
ORION = Prod. Gr. 1DA
a = Prod. Gr. 131
Hand tap set HSS, left-hand
For universal use up to 1000 N/mm2 DIN 2181

MF-L HSS
3xd
Application: Advantage:
For producing metric fine threads by hand in through ƒ Long service life and process reliability through
holes and blind holes, in steel, non-ferrous metals innovative cutting geometry and universal use for Taper tap, shape D
and (cast iron) material groups up to a strength of maximum application flexibility
1000 N/mm in single-part production.
2
Execution:
ƒ Set containing taper tap (form A) and third tap
(plug) (form C)
Third tap, shape C
Application Steel (N/mm ) 2 Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
13022 ˜ ˜ š ˜ ˜ ˜ ˜ ˜ ˜ ˜ š š
Version Set
Lead angle shape D/C
13022...
Ident. No.
mm mm mm mm mm
MF-L8 1 7 56 6 4.9 086 O. R.
MF-L10 1 9 63 7 5.5 103 O. R.
MF-L12 1 11 70 9 7 120 O. R.
MF-L12 1.5 10.5 70 9 7 126 O. R.
MF-L14 1.5 12.5 70 11 9 146 O. R.
MF-L16 1.5 14.5 70 12 9 165 O. R.
MF-L18 1.5 16.5 80 14 11 183 O. R.
MF-L20 1.5 18.5 80 16 12 203 O. R.
Set price, €
Prod. Gr. 131
Hand tap set HSS
For universal use up to 1000 N/mm2

UNC HSS
3xd
Application: Execution: Advantage:
For producing UNC (unified coarse threads) by ƒ Set containing taper tap (form A), second tap ƒ Long service life and process reliability through
hand in through holes and blind holes, in steel, non- (form D) and third tap (plug) (form C) innovative cutting geometry and universal use for
ferrous metals and (cast iron) material groups up to maximum application flexibility
a strength of 1000 N/mm in single-part production.
2

Taper tap, shape A Second tap, shape D Third tap, shape C
Application Steel (N/mm ) 2 Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
13030 ˜ ˜ š ˜ ˜ ˜ ˜ ˜ ˜ ˜ š š
Version Set
Lead angle shape A/D/C
13030...
Ident. No.
mm mm mm mm mm
UNC 3 in 48 2.1 40 2.8 2.1 030 O. R.
UNC 4 in 40 2.35 40 3.5 2.7 040 O. R.
UNC 5 in 40 2.65 40 3.5 2.7 050 O. R.
UNC 6 in 32 2.85 45 4 3 060 O. R.
