P. 137
Tools for threads
Hand screw taps
Hand tap set HSSE DIN 352 Metal cutting tools
for high-strength steels < 1300 N/mm 2
M HSSE
3xd A (6-8) D (3,5-5) C (2-3)
Application: single-part production. Ident. No. 920–952: Third tap (plug) with notch
Ident. No. 020–160: For manually tapping metric shape C without ring
threads in through holes and blind holes in the Execution:
(steel), stainless steel, (cast) and special alloy mate- Ident. No. 020–160: Set consisting of taper tap Advantage:
rial groups up to a strength of 1300 N/mm in single (form A), second tap (form D) and third tap (form Ident. No. 020–160: Long service life and high
2
part production. C) level of process reliability thanks to innovative
Ident. No. 720–952: For producing metric threads Ident. No. 720–752: Taper tap with notch shape cutting geometry for machining high-strength
by hand in through holes and blind holes, in steel, A with one ring steel
(stainless steel), cast iron and (special alloys) Ident. No. 820–852: Second tap with notch shape Ident. No. 720–952: Long service life and process
material groups up to a strength of 1300 N/mm in D with two rings reliability through innovative cutting geometry in
2
machining high-strength steel
Ident. No. 020–752 Ident. No. 020–160, 820–852 Ident. No. 020–160, 920–952
Taper tap, shape A Second tap, shape D Third tap, shape C
Application Steel (N/mm ) 2 Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
13015020-160
13015720-752
13015820-852
13015920-952
Version Set Taper tap Second tap Third tap
Lead angle shape A/D/C A D C
13015... 13015... 13015... 13015...
Ident. No. Ident. No. Ident. No. Ident. No.
mm mm mm mm mm
M2 0.4 1.6 36 2.8 2.1 020 O. R. 720 O. R. 820 O. R. 920 O. R.
M2.5 0.45 2.05 40 2.8 2.1 025 O. R. - - - - - -
M3 0.5 2.5 40 3.5 2.7 030 O. R. 730 O. R. 830 O. R. 930 O. R.
M4 0.7 3.3 45 4.5 3.4 040 O. R. 734 O. R. 834 O. R. 934 O. R.
M5 0.8 4.2 50 6 4.9 050 O. R. 738 O. R. 838 O. R. 938 O. R.
M6 1 5 50 6 4.9 060 O. R. 740 O. R. 840 O. R. 940 O. R.
M8 1.25 6.8 56 6 4.9 080 O. R. 744 O. R. 844 O. R. 944 O. R.
M10 1.5 8.5 70 7 5.5 100 O. R. 748 O. R. 848 O. R. 948 O. R.
M12 1.75 10.2 75 9 7 120 O. R. 752 O. R. 852 O. R. 952 O. R.
M14 2 12 80 11 9 140 O. R. - - - - - -
M16 2 14 80 12 9 160 O. R. - - - - - -
Set price, € Unit price, €
Prod. Gr. 131
Hand tap HSSE-PM DIN 352
for high-strength steels < 1300 N/mm 2
M HSSE- ISO 2 x
PM
3xd A (6-8) D (3,5-5) C (2-3)
Application: single-part production. Ident. No. 934–944: Third tap (plug) with notch
Ident. No. 030–120: For manually tapping metric shape C without ring
threads in through holes and blind holes in the Execution:
(steel), stainless steel, (cast) and special alloy mate- Ident. No. 030–120: Set consisting of taper tap Advantage:
rial groups up to a strength of 1300 N/mm in single (form A), second tap (form D) and third tap (form Ident. No. 030–120: Long service life and high
2
part production. C) level of process reliability thanks to innovative
Ident. No. 734–944: For producing metric threads Ident. No. 734–744: Taper tap with notch shape cutting geometry for machining high-strength
by hand in through holes and blind holes, in steel, A with one ring steel
(stainless steel), cast iron and (special alloys) Ident. No. 834–844: Second tap with notch Ident. No. 734–944: Long service life and
material groups up to a strength of 1300 N/mm in shape D with two rings process reliability through innovative cutting
2
geometry in machining high-strength steel
Ident. No. 030–120, 744–844 Ident. No. 030–120, 934–944 Ident. No. 030–740
Second tap, shape D Third tap, shape C Taper tap, shape A
Application Steel (N/mm ) 2 Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
13017030-120
13017734-744
13017834-844
13017934-944
www.buypremiumtools.com 137
