Milling tools
HSSE / PM end mill
Application Steel (N/mm ) 2 Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat. Metal cutting tools
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
15188 78 51 35 43 38 130 325 110 85 70 70 140 75 23 23 20
15902 78 51 35 43 43 130 325 70 70 110 85 140 75 23 23 20
Type N N
Surface TiAlN TiAlN
Tool holding device HB parallel HB parallel
shank shank
Z (PCS) fz steel 700 15188... 15902...
(mm) ID no. ID no.
mm mm mm mm mm
2 7 51 6 0.1 4 0.011 020 O. R. - -
3 8 52 6 0.1 4 0.022 030 O. R. - -
4 11 55 6 0.1 4 0.034 040 O. R. - -
5 13 57 6 0.1 4 0.043 050 O. R. - -
6 13 57 6 0.1 4 0.053 060 O. R. 060 O. R.
7 16 66 10 0.1 4 0.063 070 O. R. - -
8 19 69 10 0.1 4 0.073 080 O. R. 080 O. R.
10 22 72 10 0.1 4 0.09 100 O. R. 100 O. R.
12 26 83 12 0.2 4 0.1 120 O. R. 120 O. R.
14 26 83 12 0.2 4 0.11 140 O. R. - -
16 32 92 16 0.2 4 0.11 160 O. R. 160 O. R.
18 32 92 16 0.2 4 0.12 180 O. R. - -
20 38 104 20 0.2 4 0.13 200 O. R. 200 O. R.
25 45 121 25 0.2 6 0.15 250 O. R. - -
32 53 133 32 0.2 6 0.16 320 O. R. - -
Unit price, €
ORION = Prod. group 106
a = Prod. group 118
End mill, HSSE PM Milling cutter design standard DIN 844 K
4 flutes, TiAlN-coated
Application: Straight shank according to DIN 1835 B
End mill for universal processing in a wide range Also for dry milling with compressed air
of materials. Optimised flute material for delicate
clamping situations and increased service life. scope of supply and services:
10 mills in a case made of 15188
Execution:
HSSE PM Notes:
Finishing teeth Set in a case consisting of Ø
4/5/6/8/10/12/14/16/18/20 mm
Centre cutting
TiAIN coating for outstanding service life
Composition of set 4/5/6/8/10/12/14/16/18/20 mm
Number of pieces in assortment/set (PCS) 10
Type N
500
Ident. No.
15188... Set price, € O. R.
Prod. group 118
