Solid carbide milling cutter aluminium machining

Solid carbide HPC end mill Milling cutter design standard Company Metal cutting tools
4 cutting edges, ULTRA N-coated standard

Typ
VHM HPC ULTRA W Z HA
N 4 35°/38° 45°
Application: ƒ uneven 35°/38° twist angle
HPC end mill with uneven twist and uneven pitch for ƒ ZrCN ULTRA-N coated
rough and finish machining of non-ferrous metals.
Advantage:
Execution: ƒ extremely quiet running
ƒ solid carbide ultra-fine grain ƒ reduces vibrations
ƒ straight shank in accordance with DIN 6535 HA ƒ higher feeds and cutting depths possible
ƒ with edge protection chamfer ƒ ideal for static and dynamic trochoidal milling
ƒ defined edge rounding of the cutting edge ƒ defined edge rounding for maximum service life
ƒ centre cutting
ƒ with clearance
Application Steel (N/mm ) 2 Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
16652611-618 190 400 180 235 165 200 330
Type W
Surface ULTRA N
Tool holding device HA parallel
shank
Z (PCS) fz alu ˜ (mm) 16652...
ID no.
mm mm mm mm mm mm mm
4 16 22 62 3.8 6 0.1 4 0.05 611 O. R.
5 17 24 62 4.7 6 0.1 4 0.065 612 O. R.
6 18 24 62 5.6 6 0.2 4 0.07 613 O. R.
8 24 30 68 7.6 8 0.2 4 0.085 614 O. R.
10 30 38 80 9.6 10 0.2 4 0.095 615 O. R.
12 36 46 93 11.4 12 0.2 4 0.1 616 O. R.
16 48 58 108 15.4 16 0.2 4 0.12 617 O. R.
20 60 74 126 19.4 20 0.2 4 0.16 618 O. R.
Unit price, €
Prod. group 152
Solid carbide miniature torus milling cutter Milling cutter design standard Company
2 blades, ULTRA N-coated standard

VHM ULTRA Typ Z HA
N W 2
Application: ƒ Straight shank in accordance with DIN 6535 HA
Miniature torus milling cutter with long neck for ƒ Defined edge rounding of the blade
machining non-ferrous metals. ƒ Centre cutting
Execution: ƒ With clearance
ƒ Solid carbide ultra-fine grain ƒ ZrCN ULTRA N-coated

Application Steel (N/mm ) 2 Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
16653010-095 280 450 230 280 200 250 375
Type W
Surface ULTRA N
Tool holding device HA parallel
shank
Z (PCS) fz alu ˜ (mm) 16653...
ID no.
mm mm mm mm mm mm mm
0.5 0.05 0.9 4 55 0.48 4 2 0.006 010 O. R.
0.5 0.05 0.9 6 65 0.48 4 2 0.006 015 O. R.
0.5 0.08 0.9 10 65 0.48 4 2 0.006 020 O. R.
1 0.08 1.5 5 55 0.95 4 2 0.012 030 O. R.
1 0.1 1.5 10 65 0.95 4 2 0.012 035 O. R.
1 0.1 1.5 15 65 0.95 4 2 0.012 040 O. R.
1.5 0.12 1.8 8 55 1.44 4 2 0.018 050 O. R.
1.5 0.15 1.8 15 65 1.44 4 2 0.018 055 O. R.
1.5 0.15 1.8 20 65 1.44 4 2 0.018 060 O. R.
2 0.2 2 10 55 1.92 4 2 0.024 070 O. R.
2 0.2 2 20 65 1.92 4 2 0.024 075 O. R.
2.5 0.25 2.5 12 55 2.4 4 2 0.03 090 O. R.
2.5 0.25 2.5 20 65 2.4 4 2 0.03 095 O. R.
Unit price, €
Prod. group 152
