Milling tools
Solid carbide milling cutter steel machining up to 52 HRC

Solid carbide miniature torus milling cutter Milling cutter design standard Company Metal cutting tools
2 cutters, RockTec 52-coated standard

RockTec Typ Z HA
VHM N
52 2
Application: ƒ Chip angle 3°
Miniature torus milling cutter with a long neck for ƒ RockTec 52-coated
machining materials up to 52 HRC, e.g. in dip cutting ƒ Cutter tolerance Ø 0.2-0.7 mm = 0/-0.012 mm
and mould construction.
ƒ Cutter tolerance Ø 0.7-3.0 mm = 0/-0.020 mm
Execution: ƒ Radius tolerance = 0/-0.010 mm
ƒ Solid carbide ultra-fine grain Advantage:
ƒ Cutting edge finish ƒ Excellent chip removal and temperature resistance
ƒ HA shank in accordance with DIN 6535 ƒ Maximum service life thanks to RockTec 52 coating
ƒ With clearance
ƒ Type N
Application Steel (N/mm ) 2 Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
16973001-054 135 100 100 80 85 80 75 70 60 55
Type N
Surface RockTec 52
Tool holding device HA parallel
shank
Z (PCS) fz steel 16973...
1300 ˜ (mm) ID no.
mm mm mm mm mm mm mm
0.2 0.02 0.3 0.5 50 0.16 4 2 0.003 001 O. R.
0.2 0.02 0.3 1 50 0.16 4 2 0.003 002 (O. R.)
0.2 0.02 0.3 1.5 50 0.16 4 2 0.003 003 (O. R.)
0.3 0.03 0.4 1 50 0.26 4 2 0.004 004 O. R.
0.3 0.03 0.4 2 50 0.26 4 2 0.004 005 O. R.
0.3 0.03 0.4 3 50 0.26 4 2 0.004 006 (O. R.)
0.4 0.03 0.6 2 50 0.37 4 2 0.005 007 O. R.
0.4 0.03 0.6 3 50 0.37 4 2 0.005 008 O. R.
0.4 0.03 0.6 4 50 0.37 4 2 0.005 009 (O. R.)
0.4 0.03 0.6 5 50 0.37 4 2 0.005 010 (O. R.)
0.5 0.05 0.7 2 50 0.45 4 2 0.007 011 O. R.
0.5 0.05 0.7 4 50 0.45 4 2 0.007 012 O. R.
0.5 0.05 0.7 6 50 0.45 4 2 0.007 013 O. R.
0.5 0.05 0.7 8 50 0.45 4 2 0.007 014 (O. R.)
0.6 0.05 0.9 2 50 0.55 4 2 0.008 015 O. R.
0.6 0.05 0.9 4 50 0.55 4 2 0.008 016 O. R.
0.6 0.05 0.9 6 50 0.55 4 2 0.008 017 O. R.
0.6 0.05 0.9 8 50 0.55 4 2 0.008 018 (O. R.)
0.6 0.05 0.9 10 50 0.55 4 2 0.008 019 (O. R.)
0.8 0.08 1.2 4 50 0.75 4 2 0.01 020 O. R.
0.8 0.08 1.2 6 50 0.75 4 2 0.01 021 O. R.
0.8 0.08 1.2 8 50 0.75 4 2 0.01 022 O. R.
0.8 0.08 1.2 10 50 0.75 4 2 0.01 023 (O. R.)
0.8 0.08 1.2 12 50 0.75 4 2 0.01 024 (O. R.)
1 0.1 1.5 6 50 0.95 4 2 0.013 025 O. R.
1 0.1 1.5 8 50 0.95 4 2 0.013 026 O. R.
1 0.1 1.5 10 50 0.95 4 2 0.013 027 O. R.
1 0.1 1.5 12 50 0.95 4 2 0.013 028 O. R.
1 0.1 1.5 14 50 0.95 4 2 0.013 029 O. R.
1 0.1 1.5 16 60 0.95 4 2 0.013 030 O. R.
1.2 0.1 1.8 6 50 1.15 4 2 0.016 031 O. R.
1.2 0.1 1.8 10 50 1.15 4 2 0.016 032 (O. R.)
1.5 0.15 2.3 8 50 1.45 4 2 0.02 033 O. R.
1.5 0.15 2.3 12 50 1.45 4 2 0.02 034 O. R.
1.5 0.15 2.3 16 50 1.45 4 2 0.02 035 O. R.
1.5 0.15 2.3 20 60 1.45 4 2 0.02 036 (O. R.)
2 0.2 3 6 50 1.95 4 2 0.027 037 O. R.
2 0.2 3 8 50 1.95 4 2 0.027 038 O. R.
2 0.2 3 12 50 1.95 4 2 0.027 039 O. R.
2 0.2 3 16 50 1.95 4 2 0.027 040 O. R.
2 0.2 3 20 60 1.95 4 2 0.027 041 O. R.
2 0.2 3 25 75 1.95 4 2 0.027 042 (O. R.)
2.5 0.3 3.7 8 50 2.4 4 2 0.033 043 O. R.
2.5 0.3 3.7 10 50 2.4 4 2 0.033 044 O. R.
2.5 0.3 3.7 12 50 2.4 4 2 0.033 045 O. R.
2.5 0.3 3.7 16 50 2.4 4 2 0.033 046 O. R.
2.5 0.3 3.7 20 60 2.4 4 2 0.033 047 (O. R.)
2.5 0.3 3.7 25 75 2.4 4 2 0.033 048 (O. R.)
3 0.3 4.5 8 50 2.85 6 2 0.04 049 O. R.
3 0.3 4.5 10 50 2.85 6 2 0.04 050 O. R.
3 0.3 4.5 12 50 2.85 6 2 0.04 051 O. R.
3 0.3 4.5 16 60 2.85 6 2 0.04 052 O. R.
3 0.3 4.5 20 60 2.85 6 2 0.04 053 O. R.
3 0.3 4.5 25 75 2.85 6 2 0.04 054 O. R.
Unit price, €
Prod. group 152

www.buypremiumtools.com 264
