Milling tools
Solid carbide milling cutter steel machining up to 52 HRC

Type N
Surface RockTec 52
Tool holding device HA parallel
shank
Metal cutting tools
Metal cutting tools
Z (PCS) fz steel 1300 ˜ 16974...
(mm) ID no.
mm mm mm mm mm mm
1.5 1.2 12 50 1.45 4 2 0.02 140 O. R.
1.5 1.2 16 50 1.45 4 2 0.02 141 O. R.
1.5 1.2 18 60 1.45 4 2 0.02 142 O. R.
2 1.6 4 50 1.95 4 2 0.027 143 O. R.
2 1.6 8 50 1.95 4 2 0.027 144 O. R.
2 1.6 12 50 1.95 4 2 0.027 145 O. R.
2 1.6 16 50 1.95 4 2 0.027 146 O. R.
2 1.6 20 60 1.95 4 2 0.027 147 O. R.
2 1.6 25 75 1.95 4 2 0.027 148 O. R.
3 2.4 8 50 2.85 6 2 0.04 149 O. R.
3 2.4 10 50 2.85 6 2 0.04 150 O. R.
3 2.4 16 60 2.85 6 2 0.04 151 O. R.
3 2.4 20 60 2.85 6 2 0.04 152 O. R.
3 2.4 25 75 2.85 6 2 0.04 153 O. R.
Unit price, €
Prod. group 152
Solid carbide radius cutter Milling cutter design standard Company
2 cutting edges, RockTec 52-coated standard

VHM RockTec Typ Z HA
52 N 2
Application: ƒ type N
Radius cutter in standard design for machining mate- ƒ 3° chip angle
rials up to 52 HRC, e.g. in die and mould making. ƒ RockTec 52-coated
Execution: ƒ radius tolerance = 0/-0.010 mm
ƒ solid carbide ultra-fine grain Advantage:
ƒ cutting edge finish ƒ optimum chip removal and temperature resistance
ƒ HA shank in accordance with DIN 6535 ƒ maximum service life thanks to RockTec 52 coating
ƒ with clearance
Application Steel (N/mm ) 2 Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
16974200-210 175 165 130 125 110 145 110 100 90 75
Type N
Surface RockTec 52
Tool holding device HA parallel
shank
Z (PCS) fz steel 1300 ˜ 16974...
(mm) ID no.
mm mm mm mm mm mm
2 4 8 40 1.85 4 2 0.03 200 O. R.
2.5 4 10 40 2.35 4 2 0.035 201 (O. R.)
3 5 14 50 2.8 4 2 0.04 202 O. R.
4 8 20 50 3.7 4 2 0.04 203 O. R.
5 9 20 50 4.6 6 2 0.05 204 O. R.
6 10 20 50 5.5 6 2 0.06 205 O. R.
8 12 30 64 7.4 8 2 0.08 206 O. R.
10 14 32 70 9.2 10 2 0.09 207 O. R.
12 16 38 75 11 12 2 0.1 208 O. R.
16 32 46 90 15 16 2 0.12 209 O. R.
20 38 58 100 19 20 2 0.14 210 O. R.
Unit price, €
Prod. group 152
Solid carbide radius cutter Milling cutter design standard Company
2 cutting edges, RockTec 52-coated standard

VHM RockTec Typ Z HA
N
52 2
Application: ƒ type N
Radius cutter in long design for machining materials ƒ 3° chip angle
up to 52 HRC, e.g. in die and mould making. ƒ RockTec 52-coated
Execution: ƒ radius tolerance = 0/-0.010 mm
ƒ solid carbide ultra-fine grain Advantage:
ƒ cutting edge finish ƒ optimum chip removal and temperature resistance
ƒ HA shank in accordance with DIN 6535 ƒ maximum service life thanks to RockTec 52 coating
ƒ with clearance
Application Steel (N/mm ) 2 Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
16974220-230 160 150 120 110 100 130 100 90 80 65
