Milling tools
Solid carbide milling cutter steel machining up to 52 HRC

Type N
Surface RockTec 52
Tool holding device HA parallel
shank
Metal cutting tools
Metal cutting tools
Z (PCS) fz steel 1300 ˜ 16974...
(mm) ID no.
mm mm mm mm mm mm
3 5 14 50 2.8 6 4 0.03 260 O. R.
4 8 20 50 3.7 6 4 0.04 261 O. R.
5 9 20 50 4.6 6 4 0.05 262 O. R.
6 10 20 50 5.5 6 4 0.06 263 O. R.
8 12 30 64 7.4 8 4 0.08 264 O. R.
10 14 32 70 9.2 10 4 0.09 265 O. R.
12 16 38 75 11 12 4 0.1 266 O. R.
16 32 46 90 15 16 4 0.12 267 O. R.
20 38 58 100 19 20 4 0.14 268 O. R.
Unit price, €
Prod. group 152
Solid carbide radius cutter Milling cutter design standard Company
4 cutting edges, RockTec 52-coated standard

RockTec Typ Z HA
VHM
52 N 4
Application: ƒ type N
Radius cutter in long design for machining materials ƒ 3° chip angle
up to 52 HRC, e.g. in die and mould making. ƒ RockTec 52-coated
Execution: ƒ radius tolerance = 0/-0.010 mm
ƒ solid carbide ultra-fine grain Advantage:
ƒ cutting edge finish ƒ optimum chip removal and temperature resistance
ƒ HA shank in accordance with DIN 6535 ƒ maximum service life thanks to RockTec 52 coating
ƒ with clearance
Application Steel (N/mm ) 2 Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
16974270-278 160 150 120 110 100 130 100 90 80 65
Type N
Surface RockTec 52
Tool holding device HA parallel
shank
Z (PCS) fz steel 1300 ˜ 16974...
(mm) ID no.
mm mm mm mm mm mm
3 5 21 75 2.8 6 4 0.025 270 O. R.
4 8 28 75 3.7 6 4 0.035 271 O. R.
5 9 32 75 4.6 6 4 0.04 272 O. R.
6 10 40 75 5.5 6 4 0.05 273 O. R.
8 12 40 75 7.4 8 4 0.07 274 O. R.
10 14 60 100 9.2 10 4 0.08 275 O. R.
12 16 60 100 11 12 4 0.09 276 O. R.
16 32 80 125 15 16 4 0.1 277 O. R.
20 38 80 125 19 20 4 0.12 278 O. R.
Unit price, €
Prod. group 152
Solid carbide mini end mill Milling cutter design standard Company
2-cutter, RockTec 65-coated standard

VHM RockTec Typ Z HA
H
65 2
Application: ƒ Type H
Mini end mill in a short, stable design for machin- ƒ Chip angle -5°
ing materials up to 65 HRC, e.g. in dip working and ƒ RockTec 65-coated
mould forming. ƒ Cutter tolerance Ø 0.1-0.7 mm = 0/-0.012 mm
Execution: ƒ Cutter tolerance Ø 0.7-0.9 mm = 0/-0.020 mm
ƒ Solid carbide ultra-fine grain Advantage:
ƒ Cutting edge finish ƒ Excellent chip removal and temperature resistance
ƒ HA shank pursuant to DIN 6535 ƒ Maximum service life thanks to RockTec 65 coating
ƒ With clearance
Application Steel (N/mm ) 2 Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
16975001-009 120 100 95 55 80 70
