Milling tools
Solid carbide milling cutter hard material machining up to 65 HRC

Type H
Surface RockTec 65
Tool holding device HA parallel
shank
Metal cutting tools
Metal cutting tools
Z (PCS) fz hard 52 16975...
HRC ˜ (mm) ID no.
mm mm mm mm mm mm mm
3 8 20 50 2.8 6 0.1 6 0.02 240 O. R.
4 11 20 50 3.7 6 0.1 6 0.03 241 O. R.
5 13 20 50 4.6 6 0.1 6 0.04 242 O. R.
6 15 20 50 5.5 6 0.1 6 0.05 243 O. R.
8 20 30 64 7.4 8 0.2 6 0.06 244 O. R.
10 22 32 70 9.2 10 0.2 6 0.07 245 O. R.
12 25 37 75 11 12 0.2 6 0.08 246 O. R.
16 30 46 90 15 16 0.3 8 0.1 247 O. R.
20 38 58 100 19 20 0.4 8 0.13 248 O. R.
Unit price, €
Prod. group 152
SC multi-tooth mills Milling cutter design standard Company
6 cutters, RockTec 65-coated standard

RockTec Typ Z Z HA
VHM
65 H 6 8
Application: ƒ With clearance
Multi-tooth mills for circumferential, ultra-fine finish ƒ Type H
cutting and semi-rough cutting in materials up to ƒ Chip angle -26°
65 HRC.
ƒ RockTec 65-coated
Execution: Advantage:
ƒ Solid carbide ultra-fine grain ƒ Excellent chip removal and temperature resistance
ƒ Centre cutting ƒ Maximum service life thanks to RockTec 65 coating
ƒ Edge protection chamfer
ƒ HA shank in accordance with DIN 6535
Application Steel (N/mm ) 2 Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
16975250-258 180 160 125 85 125 110
Type H
Surface RockTec 65
Tool holding device HA parallel
shank
Z (PCS) fz hard 52 16975...
HRC ˜ (mm) ID no.
mm mm mm mm mm mm mm
3 19 30 75 2.8 6 0.1 6 0.018 250 (O. R.)
4 19 32 75 3.7 6 0.1 6 0.027 251 O. R.
5 19 32 75 4.6 6 0.1 6 0.03 252 O. R.
6 31 40 75 5.5 6 0.1 6 0.04 253 O. R.
8 31 40 75 7.4 8 0.2 6 0.055 254 O. R.
10 45 60 100 9.2 10 0.2 6 0.06 255 O. R.
12 50 60 100 11 12 0.2 6 0.06 256 O. R.
16 57 85 125 15 16 0.3 8 0.08 257 O. R.
20 57 85 125 19 20 0.4 8 0.1 258 O. R.
Unit price, €
Prod. group 152
Solid carbide mini torus milling cutter Milling cutter design standard Company
2 cutters, RockTec 65 coated standard

RockTec Typ Z HA
VHM H
65 2
Application: ƒ -5° -7° chip angle
Torus milling cutter with long neck for machining ƒ RockTec 65 coated
materials up to 65 HRC, e.g. for countersinking and ƒ cutting tolerance dia. 0.2-0.7 mm = 0/-0.012 mm
mould making.
ƒ cutting tolerance dia. 0.7-3.0 mm = 0/-0.020 mm
Execution: ƒ radius tolerance = 0/-0.010 mm
ƒ solid carbide ultra-fine grain Advantage:
ƒ cutting edge finish ƒ optimum chip removal and temperature resistance
ƒ HA shank in accordance with DIN 6535 ƒ maximum service life thanks to RockTec 65 coating
ƒ with clearance
ƒ type H
Application Steel (N/mm ) 2 Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
16976001-054 120 110 95 60 80 80
