Milling tools
Solid carbide milling cutter hard material machining up to 65 HRC
Type H Metal cutting tools
Surface RockTec 65
Tool holding device HA parallel
shank
Z (PCS) fz hard 52 HRC (mm) 16975...
ID no.
mm mm mm mm
0.1 0.2 40 4 2 0.001 001 (O. R.)
0.2 0.4 40 4 2 0.001 002 O. R.
0.3 0.6 40 4 2 0.001 003 O. R.
0.4 0.8 40 4 2 0.002 004 O. R.
0.5 1.2 40 4 2 0.002 005 O. R.
0.6 1.4 40 4 2 0.002 006 O. R.
0.7 1.6 40 4 2 0.003 007 (O. R.)
0.8 1.8 40 4 2 0.003 008 O. R.
0.9 1.8 40 4 2 0.004 009 (O. R.)
Unit price, €
Prod. group 152
Solid carbide mini end mill Milling cutter design standard Company
2-cutter, RockTec 65-coated standard
RockTec Typ Z HA
VHM
65 H 2
Application: Type H
Mini end mill with a long neck for machining materi- Chip angle -5°/-7°
als up to 65 HRC, e.g. in dip working and mould RockTec 65-coated
forming.
Cutter tolerance Ø 0.1-0.7 mm = 0/-0.012 mm
Execution: Cutter tolerance Ø 0.7-3.0 mm = 0/-0.020 mm
Solid carbide ultra-fine grain Advantage:
Cutting edge finish Excellent chip removal and temperature resistance
HA shank pursuant to DIN 6535 Maximum service life thanks to RockTec 65 coating
With clearance
Application Steel (N/mm ) 2 Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
16975100-153 120 100 95 55 80 70
Type H
Surface RockTec 65
Tool holding device HA parallel
shank
Z (PCS) fz hard 52 16975...
HRC (mm) ID no.
mm mm mm mm mm mm
0.2 0.3 0.5 50 0.16 4 2 0.002 100 O. R.
0.2 0.3 1 50 0.16 4 2 0.002 101 O. R.
0.2 0.3 1.5 50 0.16 4 2 0.002 102 (O. R.)
0.3 0.4 1 50 0.26 4 2 0.003 103 (O. R.)
0.3 0.4 2 50 0.26 4 2 0.003 104 O. R.
0.3 0.4 3 50 0.26 4 2 0.003 105 (O. R.)
0.4 0.6 2 50 0.37 4 2 0.004 106 O. R.
0.4 0.6 3 50 0.37 4 2 0.004 107 O. R.
0.4 0.6 4 50 0.37 4 2 0.004 108 (O. R.)
0.4 0.6 5 50 0.37 4 2 0.004 109 (O. R.)
0.5 0.7 2 50 0.45 4 2 0.005 110 O. R.
0.5 0.7 4 50 0.45 4 2 0.005 111 O. R.
0.5 0.7 6 50 0.45 4 2 0.005 112 O. R.
0.5 0.7 8 50 0.45 4 2 0.005 113 (O. R.)
0.6 0.9 2 50 0.55 4 2 0.006 114 O. R.
0.6 0.9 4 50 0.55 4 2 0.006 115 O. R.
0.6 0.9 6 50 0.55 4 2 0.006 116 O. R.
0.6 0.9 8 50 0.55 4 2 0.006 117 (O. R.)
0.6 0.9 10 50 0.55 4 2 0.006 118 (O. R.)
0.8 1.2 4 50 0.75 4 2 0.008 119 O. R.
0.8 1.2 6 50 0.75 4 2 0.008 120 O. R.
0.8 1.2 8 50 0.75 4 2 0.008 121 O. R.
0.8 1.2 10 50 0.75 4 2 0.008 122 (O. R.)
0.8 1.2 12 50 0.75 4 2 0.008 123 (O. R.)
1 1.5 6 50 0.95 4 2 0.01 124 O. R.
1 1.5 8 50 0.95 4 2 0.01 125 O. R.
1 1.5 10 50 0.95 4 2 0.01 126 O. R.
1 1.5 12 50 0.95 4 2 0.01 127 O. R.
1 1.5 14 50 0.95 4 2 0.01 128 (O. R.)
1 1.5 16 60 0.95 4 2 0.01 129 O. R.
1.2 1.8 6 50 1.15 4 2 0.012 130 O. R.
1.2 1.8 10 50 1.15 4 2 0.012 131 O. R.
1.5 2.3 8 50 1.45 4 2 0.015 132 O. R.
1.5 2.3 12 50 1.45 4 2 0.015 133 O. R.
1.5 2.3 16 50 1.45 4 2 0.015 134 O. R.
1.5 2.3 20 60 1.45 4 2 0.015 135 (O. R.)
2 3 6 50 1.95 4 2 0.02 136 O. R.
2 3 8 50 1.95 4 2 0.02 137 O. R.
2 3 12 50 1.95 4 2 0.02 138 O. R.
2 3 16 50 1.95 4 2 0.02 139 O. R.
