Milling tools
Solid carbide milling cutter hard material machining up to 65 HRC

Type H
Surface RockTec 65
Tool holding device HA parallel
shank
Metal cutting tools
Metal cutting tools
Z (PCS) fz hard 52 16975...
HRC ˜ (mm) ID no.
mm mm mm mm mm mm
2 3 20 60 1.95 4 2 0.02 140 O. R.
2 3 25 75 1.95 4 2 0.02 141 (O. R.)
2.5 3.7 8 50 2.4 4 2 0.025 142 O. R.
2.5 3.7 10 50 2.4 4 2 0.025 143 (O. R.)
2.5 3.7 12 50 2.4 4 2 0.025 144 O. R.
2.5 3.7 16 50 2.4 4 2 0.025 145 O. R.
2.5 3.7 20 60 2.4 4 2 0.025 146 O. R.
2.5 3.7 25 75 2.4 4 2 0.025 147 (O. R.)
3 4.5 8 50 2.85 6 2 0.03 148 O. R.
3 4.5 10 50 2.85 6 2 0.03 149 (O. R.)
3 4.5 12 50 2.85 6 2 0.03 150 O. R.
3 4.5 16 60 2.85 6 2 0.03 151 O. R.
3 4.5 20 60 2.85 6 2 0.03 152 O. R.
3 4.5 25 75 2.85 6 2 0.03 153 (O. R.)
Unit price, €
Prod. group 152
Solid carbide end mill Milling cutter design standard Company
4 cutters, RockTec 65-coated standard

VHM RockTec Typ Z HA
65 H 4
Application: ƒ With clearance
End mill in a standard design for machining ma- ƒ Type H
terials up to 65 HRC, e.g. dip cutting and mould ƒ Chip angle -6°
construction. ƒ RockTec 65-coated
Execution: Advantage:
ƒ Solid carbide ultra-fine grain ƒ Excellent chip removal and temperature resistance
ƒ Cutting edge finish ƒ Maximum service life thanks to RockTec 65 coating
ƒ HA shank in accordance with DIN 6535
Application Steel (N/mm ) 2 Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
16975200-208 200 180 140 95 140 120
Type H
Surface RockTec 65
Tool holding device HA parallel
shank
Z (PCS) fz hard 52 16975...
HRC ˜ (mm) ID no.
mm mm mm mm mm mm
3 9 15 50 2.8 6 4 0.027 200 O. R.
4 12 20 50 3.7 6 4 0.036 201 O. R.
5 15 20 50 4.6 6 4 0.045 202 O. R.
6 16 20 50 5.5 6 4 0.055 203 O. R.
8 20 30 64 7.4 8 4 0.07 204 O. R.
10 22 32 70 9.2 10 4 0.08 205 O. R.
12 25 37 75 11 12 4 0.09 206 O. R.
16 32 46 90 15 16 4 0.11 207 O. R.
20 38 58 100 19 20 4 0.14 208 O. R.
Unit price, €
Prod. group 152
Solid carbide end mill Milling cutter design standard Company
4 cutters, RockTec 65-coated standard

VHM RockTec Typ Z HA
H
65 4
Application: ƒ With clearance
End mill, long, with short cutters for machining ƒ Type H
materials up to 65 HRC, e.g. in dip cutting and mould ƒ Chip angle -6°
construction. ƒ RockTec 65-coated
Execution: Advantage:
ƒ Solid carbide ultra-fine grain ƒ Excellent chip removal and temperature resistance
ƒ Cutting edge finish ƒ Maximum service life thanks to RockTec 65 coating
ƒ HA shank in accordance with DIN 6535
Application Steel (N/mm ) 2 Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
16975220-228 180 160 125 85 125 110
