Milling tools
Solid carbide milling cutter hard material machining up to 65 HRC

Type H
Surface RockTec 65
Tool holding device HA parallel
shank
Metal cutting tools
Metal cutting tools
Z (PCS) fz hard 52 16976...
HRC ˜ (mm) ID no.
mm mm mm mm mm mm mm
10 1 14 85 125 9.2 10 4 0.06 180 O. R.
10 2 14 85 125 9.2 10 4 0.06 181 O. R.
12 1 16 110 150 11 12 4 0.07 182 O. R.
12 2 16 110 150 11 12 4 0.07 183 O. R.
16 1 22 110 150 15 16 4 0.09 184 (O. R.)
16 2 22 110 150 15 16 4 0.09 185 (O. R.)
Unit price, €
Prod. group 152
Solid carbide HSC high-feed milling cutter Milling cutter design standard Company
4 flutes, RockTec 65-coated standard

Z
VHM HSC RockTec Typ 4 Z HA
H
6
65
Application: 3° ƒ Type H
High-feed milling cutter (HSC) with short blade for ƒ Chip angle -1°
processing materials up to 65 HRC. Applications ƒ Twist angle 3°
in die and mould making and general mechanical ƒ RockTec 65-coated
engineering.
Advantage:
Execution: ƒ High material removal rate, high surface quality
ƒ Solid carbide ultra-fine grain ƒ High feeds of 0.2-0.5 mm per tooth possible
ƒ HA shank in line with DIN 6535 ƒ Good dimensional and geometric accuracy
ƒ Cutting edge finish ƒ RockTec 65 coating for maximum service life
ƒ Centre cutting
Application Steel (N/mm ) 2 Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
16976190-201 170 160 140 90 120
Type H
Surface RockTec 65
Tool holding device HA parallel
shank
Z (PCS) fz hard 52 16976...
HRC ˜ (mm) ID no.
mm mm mm mm mm mm mm
4 0.4 1.5 8 57 3.7 6 4 0.13 190 O. R.
4 0.4 1.5 15 57 3.7 6 4 0.13 191 O. R.
5 0.5 2 10 57 4.6 6 4 0.17 192 O. R.
5 0.5 2 21 57 4.6 6 4 0.17 193 O. R.
6 0.6 2.5 12 57 5.5 6 4 0.2 194 O. R.
6 0.6 2.5 26 57 5.5 6 4 0.2 195 O. R.
8 0.8 3 16 63 7.4 8 6 0.24 196 O. R.
8 0.8 3 31 63 7.4 8 6 0.24 197 O. R.
10 1 3.5 20 72 9.2 10 6 0.34 198 O. R.
10 1 3.5 36 72 9.2 10 6 0.34 199 O. R.
12 1.2 4 24 83 11 12 6 0.42 200 O. R.
12 1.2 4 41 83 11 12 6 0.42 201 O. R.
Unit price, €
Prod. group 152

Solid carbide mini radius milling cutter Milling cutter design standard Company
2 cutting edges, RockTec 65-coated standard

VHM RockTec Typ Z HA
65 H 2
Application: ƒ RockTec 65 coated up to 65 HRC
Mini radius cutter in short, sturdy design for machin- ƒ cutting edge tolerance, dia. 0.2-0.7 mm = 0/-0.012
ing materials up to 65 HRC. mm
Execution: ƒ cutting edge tolerance, dia. 0.7-0.9 mm = 0/-0.020
mm
ƒ solid carbide ultra-fine grain
ƒ cutting edge finish Advantage:
ƒ HA shank in accordance with DIN 6535 ƒ optimum chip removal and temperature resistance
ƒ type H ƒ maximum service life thanks to RockTec 65 coating
ƒ -5° chip angle
2
Application Steel (N/mm ) Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
16977001-008 130 110 105 60 90 80
