Milling tools
Solid carbide milling cutter hard material machining up to 65 HRC

Type H
Surface RockTec 65
Tool holding device HA parallel
shank
Metal cutting tools
Metal cutting tools
Z (PCS) fz hard 52 HRC ˜ (mm) 16977...
ID no.
mm mm mm mm
0.2 0.4 40 4 2 0.002 001 O. R.
0.3 0.6 40 4 2 0.003 002 O. R.
0.4 0.8 40 4 2 0.003 003 O. R.
0.5 1 40 4 2 0.003 004 O. R.
0.6 1.4 40 4 2 0.003 005 O. R.
0.7 1.6 40 4 2 0.003 006 (O. R.)
0.8 1.8 40 4 2 0.003 007 O. R.
0.9 2 40 4 2 0.004 008 (O. R.)
Unit price, €
Prod. group 152
Solid carbide mini radius milling cutter Milling cutter design standard Company
2 cutting edges, RockTec 65-coated standard

VHM RockTec Typ Z HA
H
65 2
Application: ƒ RockTec 65-coated
Mini radius cutter with long neck for machining ƒ cutting edge tolerance, dia. 0.2-0.7 mm = 0/-0.012
materials up to 65 HRC. mm
Execution: ƒ cutting edge tolerance, dia. 0.7-3.0 mm = 0/-0.020
mm
ƒ solid carbide ultra-fine grain ƒ radius tolerance = 0/-0.010 mm
ƒ cutting edge finish
ƒ HA shank in accordance with DIN 6535 Advantage:
ƒ with clearance ƒ optimum chip removal and temperature resistance
ƒ type H ƒ maximum service life thanks to RockTec 65 coating
ƒ -5° chip angle
Application Steel (N/mm ) 2 Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
16977100-153 220 200 155 105 155 130
Type H
Surface RockTec 65
Tool holding device HA parallel
shank
Z (PCS) fz hard 52 16977...
HRC ˜ (mm) ID no.
mm mm mm mm mm mm
0.2 0.2 0.5 50 0.15 4 2 0.003 100 O. R.
0.2 0.2 1 50 0.15 4 2 0.003 101 O. R.
0.2 0.2 1.5 50 0.15 4 2 0.003 102 O. R.
0.3 0.3 1 50 0.25 4 2 0.003 103 O. R.
0.3 0.3 2 50 0.25 4 2 0.003 104 O. R.
0.3 0.3 3 50 0.25 4 2 0.003 105 (O. R.)
0.4 0.4 1 50 0.35 4 2 0.004 106 O. R.
0.4 0.4 2 50 0.35 4 2 0.004 107 O. R.
0.4 0.4 3 50 0.35 4 2 0.004 108 O. R.
0.4 0.4 4 50 0.35 4 2 0.004 109 (O. R.)
0.4 0.4 5 50 0.35 4 2 0.004 110 (O. R.)
0.5 0.4 2 50 0.45 4 2 0.006 111 O. R.
0.5 0.4 3 50 0.45 4 2 0.006 112 O. R.
0.5 0.4 4 50 0.45 4 2 0.006 113 O. R.
0.5 0.4 5 50 0.45 4 2 0.006 114 O. R.
0.5 0.4 6 50 0.45 4 2 0.006 115 O. R.
0.5 0.4 8 50 0.45 4 2 0.006 116 (O. R.)
0.6 0.5 2 50 0.55 4 2 0.007 117 O. R.
0.6 0.5 3 50 0.55 4 2 0.007 118 O. R.
0.6 0.5 4 50 0.55 4 2 0.007 119 O. R.
0.6 0.5 5 50 0.55 4 2 0.007 120 O. R.
0.6 0.5 6 50 0.55 4 2 0.007 121 O. R.
0.6 0.5 8 50 0.55 4 2 0.007 122 (O. R.)
0.8 0.6 2 50 0.75 4 2 0.009 123 O. R.
0.8 0.6 4 50 0.75 4 2 0.009 124 O. R.
0.8 0.6 5 50 0.75 4 2 0.009 125 O. R.
0.8 0.6 6 50 0.75 4 2 0.009 126 O. R.
0.8 0.6 7 50 0.75 4 2 0.009 127 (O. R.)
0.8 0.6 8 50 0.75 4 2 0.009 128 O. R.
0.8 0.6 10 50 0.75 4 2 0.009 129 O. R.
1 0.8 3 50 0.95 4 2 0.01 130 O. R.
1 0.8 6 50 0.95 4 2 0.01 131 O. R.
1 0.8 8 50 0.95 4 2 0.01 132 O. R.
1 0.8 10 50 0.95 4 2 0.01 133 O. R.
1 0.8 12 50 0.95 4 2 0.01 134 O. R.
1 0.8 16 50 0.95 4 2 0.01 135 O. R.
1 0.8 20 60 0.95 4 2 0.01 136 O. R.
1.2 1 6 50 1.15 4 2 0.01 137 O. R.
1.2 1 10 50 1.15 4 2 0.01 138 (O. R.)
1.5 1.2 8 50 1.45 4 2 0.02 139 O. R.
