Milling tools
Solid carbide milling cutter hard material machining up to 65 HRC
Type H Metal cutting tools
Surface RockTec 65
Tool holding device HA parallel
shank
Z (PCS) fz hard 52 16977...
HRC (mm) ID no.
mm mm mm mm mm mm
1.5 1.2 12 50 1.45 4 2 0.02 140 O. R.
1.5 1.2 16 50 1.45 4 2 0.02 141 O. R.
1.5 1.2 18 60 1.45 4 2 0.02 142 O. R.
2 1.6 4 50 1.95 4 2 0.02 143 O. R.
2 1.6 8 50 1.95 4 2 0.02 144 O. R.
2 1.6 12 50 1.95 4 2 0.02 145 O. R.
2 1.6 16 50 1.95 4 2 0.02 146 O. R.
2 1.6 20 60 1.95 4 2 0.02 147 O. R.
2 1.6 25 75 1.95 4 2 0.02 148 O. R.
3 2.4 8 50 2.85 6 2 0.03 149 O. R.
3 2.4 10 50 2.85 6 2 0.03 150 O. R.
3 2.4 16 60 2.85 6 2 0.03 151 O. R.
3 2.4 20 60 2.85 6 2 0.03 152 O. R.
3 2.4 25 75 2.85 6 2 0.03 153 O. R.
Unit price, €
Prod. group 152
Solid carbide radius milling cutter Milling cutter design standard Company
2 cutters, RockTec 65-coated standard
VHM RockTec Typ Z HA
65 H 2
Application: Type H
Radius milling cutter, standard design, for machining Chip angle -10°
materials up to 65 HRC, e.g. in dip cutting and mould RockTec 65-coated
construction. Radius tolerance = 0/-0.010 mm
Execution: Advantage:
Solid carbide ultra-fine grain Excellent chip removal and temperature resistance
Cutting edge finish Maximum service life thanks to RockTec 65 coating
HA shank in accordance with DIN 6535
With clearance
Application Steel (N/mm ) 2 Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
16977200-210 220 200 155 105 155 130
Type H
Surface RockTec 65
Tool holding device HA parallel
shank
Z (PCS) fz hard 52 16977...
HRC (mm) ID no.
mm mm mm mm mm mm
2 4 8 40 1.85 4 2 0.025 200 O. R.
2.5 4 10 40 2.35 4 2 0.03 201 O. R.
3 5 14 50 2.8 4 2 0.035 202 O. R.
4 8 20 50 3.7 4 2 0.035 203 O. R.
5 9 20 50 4.6 6 2 0.04 204 O. R.
6 10 20 50 5.5 6 2 0.05 205 O. R.
8 12 30 64 7.4 8 2 0.07 206 O. R.
10 14 32 70 9.2 10 2 0.08 207 O. R.
12 16 38 75 11 12 2 0.09 208 O. R.
16 32 46 90 15 16 2 0.1 209 O. R.
20 38 58 100 19 20 2 0.12 210 (O. R.)
Unit price, €
Prod. group 152
Solid carbide radius milling cutter Milling cutter design standard Company
2 cutters, RockTec 65-coated standard
VHM RockTec Typ Z HA
H
65 2
Application: Type H
Radius milling cutter, long design, for machining Chip angle -10°
materials up to 65 HRC, e.g. in dip cutting and mould RockTec 65-coated
construction.
Radius tolerance = 0/-0.010 mm
Execution: Advantage:
Solid carbide ultra-fine grain Excellent chip removal and temperature resistance
Cutting edge finish Maximum service life thanks to RockTec 65 coating
HA shank in accordance with DIN 6535
With clearance
