Lathe tools
ISO clamp holders for external machining

DCLN R/L clamp holder, negative DIN 4983
for face and longitudinal lathing with CN indexable insert
Metal cutting tools
Metal cutting tools
Application: Advantage:
For face and longitudinal turning with CN indexable ƒ Universal use for face and longitudinal turning with
insert, 80°. large feed depths and unfavourable conditions
Execution: ƒ Negative geometry of the body ensures good
stability and force absorption at large cutting
ƒ Ident. No. 010, 015, 017, 019, 021: Precision- depths
manufactured steel support, burnished, hardened, ƒ Broad range of use: suitable for both finishing and
adjustable clamping system, type C, working angle roughing operations
95°, tip angle 80°, clearance angle 0°
ƒ Ident. No. 011, 016, 018, 020, 022: Precision- ƒ Adjustable clamp minimises vibrations and ensures
good force transfer
manufactured steel support, burnished, hardened, f b
adjustable clamp, adjustable clamping system, h1 h
type C, working angle 95°, tip angle 80°, clearance l2 l1
angle 0°
Tool design Right Left
ISO name h=h1 (mm) b (mm) l2 (mm) l1 (mm) f (mm) Suitable for in- 17826... 17826...
dexable inserts ID no. ID no.
DCLN R/L 2020 010 O. R. 011 O. R.
K12 20 20 28 125 25 CN.. 1204..
DCLN R/L 2525 25 25 28 150 32 CN.. 1204.. 015 O. R. 016 O. R.
M12
DCLN R/L 3232 32 32 28 170 40 CN.. 1906.. 017 O. R. 018 O. R.
P12
DCLN R/L 3232 32 32 42 170 40 CN.. 1906.. 019 O. R. 020 O. R.
P19
DCLN R/L 4040 40 40 43 250 50 CN.. 1906.. 021 O. R. 022 (O. R.)
S19
Unit price, €
Prod. group 107
