Lathe tools
ISO clamp holders for external machining

DDJN R/L clamp holder, negative DIN 4983 Metal cutting tools
for copy and longitudinal lathing with DN indexable insert
Application: Advantage:
For copy and longitudinal turning with DN indexable ƒ Streamlined geometry, optimised for contour lathe
insert, 55°. work with large feed depths and unfavourable
conditions
Execution: ƒ Negative geometry of the body ensures good
ƒ Precision-manufactured steel support, burnished, stability and force absorption at large cutting
hardened, adjustable clamping system, type D, depths
working angle 93°, tip angle 55°, clearance angle ƒ Broad range of use: suitable for both finishing and
0° roughing operations
ƒ Adjustable clamp minimises vibrations and ensures
good force transfer f b
h1 h
l2
l1
Tool design Right Left
ISO name h=h1 (mm) b (mm) l2 (mm) l1 (mm) f (mm) Suitable for 17826... 17826...
indexable inserts ID no. ID no.
DDJN R/L 2020 20 20 30 125 25 DN.. 1104.. 100 O. R. 101 O. R.
K11
DDJN R/L 2525 25 25 30 150 32 DN.. 1104.. 105 O. R. 106 O. R.
M11
DDJN R/L 2020 20 20 34 125 25 DN.. 1506.. 110 O. R. 111 O. R.
K15
DDJN R/L 2525 25 25 34 150 32 DN.. 1506.. 115 O. R. 116 O. R.
M15
Unit price, €
Prod. group 107

MTEN clamp holder, negative, neutral DIN 4983
For copy and longitudinal turning with TN indexable insert

Application: Advantage:
For copy and longitudinal turning with TN indexable ƒ Triple-edge geometry lowers cost per cut
insert, 60°. ƒ Negative geometry of the body ensures good
Execution: stability and force absorption at large cutting
depths
ƒ Precision-manufactured steel support, burnished, ƒ Broad range of use: suitable for both finishing and
hardened, adjustable clamping system, type T, roughing operations
working angle 93°, tip angle 60°, clearance angle
0° ƒ Adjustable clamp minimises vibrations and ensures
good force transfer f b
h1 h
50°
l2
l1
Tool design Neutral
ISO name h=h1 (mm) b (mm) l1 (mm) l2 (mm) f (mm) Suitable for index- 17859...
able inserts ID no.
MTEN N 2020 K16 20 20 125 34 10.5 TN.. 1604.. 001 O. R.
MTEN N 2525 M16 25 25 150 34 13 TN.. 1604.. 002 O. R.
Unit price, €
Prod. group 107
