01 WIRING ACCESSORIES
WIRE / CABLE MARKING SYSTEM
EC TYPE CABLE MARKER
MATERIAL
Soft PVC, concave conversed shape, number code in sleeve elasticity of in-diameter.
Suitable Wire Range Packing
Part No Colour Wire (mm) Marking (pcs/roll) Price
(mm²)
EC - 0 0.75 - 1.5 2.0 - 3.2 0 - 9, A - Z, + - / \ 1000 18.60
EC - 1 0.75 - 3.5 3.0 - 4.2 0 - 9, A - Z, + - / \ 1000 4.50
EC - 2 3.5 - 8.0 3.6 - 7.4 0 - 9, A - Z, + - / \ 500 16.00
EC - 3 5.2 - 10.0 5.2 - 10.0 0 - 9, A - Z, + - / \ 250 16.00
Yellow, Y White, W
FLAT CABLE MARKER
MATERIAL
Soft PVC, elasticity of in-diameter.
With its unique oval shape design provides:
1. Slip over cable directly (for small cable)
2. Slip onto marker strip (for large cable or cable bundles)
Suitable Wire Range Packing
Part No Colour Wire (mm) Marking (pcs/roll) Price
(mm²)
FM - 1 2.0 - 8.0 3.5 - 7.0 0 - 9, A - Z, + - / \ 500 17.50
Yellow, Y
CABLE MARKER STRIP
MAT ERIAL
Nylon 66 PLATE with cable tie fastening hole to accommodate marker pieces for easy
identification of cable runs.
Marking Packing
Part No Digit Price
W (mm) L (mm) (pcs/pkt)
MS - 65 9.0 65.0 9.0 100 11.00
MS - 100 9.0 100.0 16.0 100 18.00
MS - 135 9.0 135.0 23.0 100 31.00
L
W
Atca Catalog | Safe Connect Together 1.04
