Page 663 - 2006 HARLEY FLSTCI SERVICE MANUAL

2.9 SEALED 2.10 WHEEL
2.6

CLEANING AND INSPECTION
wheel bearings must be serviced, see Inspect all parts for damage or excessive wear. If sealed WHEEL BEARINGS 11WARNING 1WARNING Always replace brake pads in complete sets for correct and safe brake operation. Improper brake operation could result in death or serious injury. (00111a) Inspect brake rotor and pads. Minimum brake pad thickness: 0.06 in. (1.6 mm) or less above the backing plate. Minimum brake disc thickness is stamped on the side of the disc. Replace disc if badly scored. Maximum brake disc lateral runout and warpage is 0.008 in. (0.2 mm). If hub and rim were disassembled, see LACING: 16 IN. RIM. Verify that whee

1. 2. a. b. c. ASSEMBLY 1. 2. LACED WHEEL. 3. 4. bearings.

FRONT WHEEL: FLSTSC
SPECIALTY TOOL Hub cap remover/installer Block motorcycle underneath frame so front wheel is Inspect wheel bearing end play and service bearings if necessary. See 2.9 SEALED WHEEL BEARINGS. Remove front brake caliper. See 2.19 FRONT BRAKE CALIPER: FLSTSC. Support caliper using a rubber bun- gee cord. Be careful not to scratch the fender paint. NOTE Do not operate front brake lever with the front wheel removed or the caliper piston may be forced out of piston bore. Reseat- ing the piston requires disassembly of the caliper. See Figure 2-10. Remove hub caps (1, 25) and hub cap seals (2, 24) using HUB CAP REMOVER/INSTALLER Label wheel

REMOVAL PART NO. HD-41494 raised off the ground. (Part No. HD-41494). tation (fork side or wheel side). may fall from hub. DISASSEMBLY disc. 2006 Softail: Chassis
