METALWORKING EQUIPMENT AND TOOLS

Conclusions
1. The design of a block boring tool has been developed at the level of utility model
patents, replacing a solid boring tool for roughing and semi-finishing processing of holes
with a ratio of the extension of the boring mandrel to the diameter of the hole within the
range from 3.5 to 6.
2. Separate blocks of the proposed set of boring tools were manufactured at the Orsha
Tool Plant at the request of " MSTU " STANKIN " to equip the DMC 630 ecoline multi-
purpose machine, passed production quality control and tested in laboratory conditions.
3. The expected economic effect from the use of development in one flexible production of
two multi-purpose machines - at least 25,000 rubles a year due to a significant reduction
in the cost of manufacturing special boring mandrels when updating production facilities,
as well as by reducing the cost of storing the tool and preparing him to work.

R.E. Aldangurov, graduate student
A.R. Maslov, supervisor, doctor of technical sciences, professor
MSTU "STANKIN", department "Highly efficient technologies processing."

References:
1. Grigoriev S.N. Tooling for CNC machines: a reference / Grigoryev S.N., Kokhomsky M.V., Maslov A.R. Moscow.
Mechanical Engineering. 2006. 544 p.
2. Maslov A.R. Instrumental systems of engineering production: a textbook for universities. Moscow. "Engineering".
2006. 335 p.
3. Reference book of the technologist-machine builder. In 2 vol. E.1 / Ed. A.M. Dalsky, A.G. Kosilova, R.K.
Meshcheryakova et al. 5th ed., Rev. and add. Moscow. Mechanical Engineering-1, 2001, 912 p., Ill.

Connection of vibration with acoustic emission of working
machines

The results of type tests of a bench-drilling machine are presented, during which
a qualitative and quantitative relationship of the amplitude of vibration acceleration,
converted to the equivalent logarithmic level of pressure with the measured the values of
both parameters at free running
The process of improving the design of the dynamics of machine tools carried
of technological machines, the progress out at free running and technological run
of their competitive development is based are considered the simplest, allowing
on many studies related to finding ways reliable assessment of internal and external
to improve the dynamics of their work, relationships with good reproducibility of
especially in transient processes of cutting a the studied parameters.
cutting tool into a workpiece. The direction A retrospective analysis of the global
of creating working machines on a new production of machine tools for 2014
element base for additive technologies is showed: in terms of machine consumption
supported by the National Technological (in millions of dollars), Russia took 7th
Initiative program. The presence of modern place in the world with a volume of 2.0, for
technical means of measurement allows us manufacturing - 20th place, for import - 4th
to quantitatively evaluate the variation of the place (1.87), export - 24th place (73.3),
measured vibration components: vibration on the consumption of machine tools per
displacement, vibration velocity, vibration capita - 21 place (14.13). These "sparkling"
acceleration, and in certain technological indicators testify to the loss of the Russian
processes and vibration reduction as a machine-tool industry and the relevance
function of the response of a machine of the revival of both research and the
dynamic system with its own elasticity and production of competitive precision-class
internal energy. At the same time, studies machines [1].
