Page 179 - 2018 Allstar Performance Parts and Equipment Catalog

Steel Control Arm Bushings Roller Bearing
Allstar Steel Control Arm Bushings replace Lower Control Arm Bushings SUSPENSION
stock rubber bushings and eliminate Free up stock front suspensions and help
deflection, a common problem with prevent binding commonly found with
original equipment bushings. ALL56230 stock rubber and steel insert bushings. ALL56223
Steel bodied bushings are complete with
Lower Control Arm Bushing Applications
needle roller bearings and hardened
Part No. Application Bushing Position O.D. UHL Hole Size inserts that are ready to install and do
Chevelle, Monte Carlo, GM Intermediates not require special mounting hardware.
1964-66 Front (2nd Design) 1.345" 2.100" .500"
ALL56230 All Bushings have 1/2" I.D. mounting
1967-74 Front 1.345" 2.100" .500"
1964-66 Front (1st Design) 1.645" 2.100" .500" holes.
1975-77 Front 1.645" 2.100" .500"
ALL56232
1964-72 Rear 1.645" 2.100" .500" Part No. Application Bushing Position O.D. UHL Hole Size
1978-88 Rear 1.645" 2.100" .500" Chevelle, Monte Carlo, GM Intermediates
ALL56233 – – 1.645" 2.100" .562" 1964-66 Front (2nd Design) 1.345" 2.100" .500"
ALL56234 1973-77 Rear 1.900" 2.100" .500" ALL56221 1967-74 Front 1.345" 2.100" .500"
ALL56235 – – 1.900" 2.100" .562" 1964-66 Front (1st Design) 1.645" 2.100" .500"
ALL56236 1978-88 Front 1.440" 2.750" .500" 1975-77 Front 1.645" 2.100" .500"
Camaro, Firebird ALL56222 1964-72 Rear 1.645" 2.100" .500"
ALL56230 1967-74 Front 1.345" 2.100" .500" 1978-88 Rear 1.645" 2.100" .500"
1975-81 Front 1.645" 2.100" .500"
ALL56232 ALL56223 1973-77 Rear 1.900" 2.100" .500"
1967-72 Rear 1.645" 2.100" .500"
ALL56234 1973-88 Rear 1.900" 2.100" .500" ALL56224 1978-88 Front 1.440" 2.750" .500"
ALL56236 1982-92 Front 1.440" 2.750" .500" Camaro, Firebird
ALL56221 1967-74 Front 1.345" 2.100" .500"
Upper Control Arm Bushing Applications ALL56222 1975-81 Front 1.645" 2.100" .500"
Part No. Application Bushing Position O.D. UHL Hole Size 1967-72 Rear 1.645" 2.100" .500"
Rear
Chevelle, Monte Carlo, GM Intermediates ALL56223 1973-88 Front 1.900" 2.100" .500"
.500"
ALL56224
1982-92
1.440" 2.750"
ALL56238 1967-72 All 1.275" 1.250" .675"
ALL56240 1978-88 All 1.530" 1.500" .695" Related Parts
ALL56242 1973-77 Front 1.394" 1.500" .690" ALL56226 ..... Nylon Bushing Kit
ALL56244 1973-77 Rear 1.311" 1.425" .690" (Optional bushings to replace roller bearings when con-
Camaro, Firebird forming to some sanctioning body rules.)
ALL56238 1967-69 All 1.275" 1.250" .675"
ALL56242 1974-79 Front 1.394" 1.500" .690"
ALL56244 1974-79 Rear 1.311" 1.425" .690"
