Chief Architect X10 Reference Manual

and floors. The fill style for walls is
specified for the wall layer in the wall
type definition. The fill style for footings
is “Concrete”. The fill style for the floor
is set in the floor platform definition.
• Slabs - Closed polylines using the
“Concrete” fill style are created for
Slabs . See “The Slab Tools” on page
702.
• Material Regions - Closed polylines for
each layer of a Wall or Floor Material
Region or a Custom Backsplash are
created. The polylines use the fill style
Auto Detail creates CAD objects in specified in the object’s material layers
walls, floor and ceiling platforms, foundation definition. See “Floor and Wall Material
walls and footings, slabs, roof and ceiling Regions” on page 998.
planes, as well as Material Regions and Regardless of the fill style specified for a
Custom Backslashes that are intersected by layer, if the associated material is assigned
the cross section plane as follows: the Material Type of “Gap”, no CAD object
• Walls - Creates closed CAD polylines for will be created to detail that layer. See
each wall layer with a fill style specified “Material Types” on page 1024.
in the wall type definition. The polyline The CAD objects created by the Auto
uses the same fill as that specified for the
wall layer. See “Wall Type Definitions” Detail tool are placed on the Current
on page 383. CAD Layer. See “Current CAD Layer” on
page 323.
• Floors and Ceilings - Creates closed
CAD polylines for each floor and ceiling Note that using the Auto Detail tool
layer with a fill style specified in the twice results in two copies of the same CAD
Platform or Finish definition. See “Floor objects.
and Ceiling Platform Definitions” on
page 428. Once created, these CAD objects can be
selected and edited. See “Editing Closed-
• Roof and Ceiling Planes - Creates Polyline Based Objects” on page 231 and
closed CAD polylines for each roof layer “Editing Box-Based Objects” on page 236.
with a fill style specified in its Surface,
Structure, or Ceiling definition. See
“Roof Layers” on page 790. Insulation
• Foundations - Closed polylines are Instead of using the fill style specified for a
created for foundation walls, footings, given material layer, the Auto Detail t o o l

1056
