DURABLASTER WHEEL CLEANER

Maintenance

Trouble Shooting Tire Sensing Photo-Eyes and Bell Hose

Problem Cause Solution
Device not  Not programmed properly  Review program
turning ON  Dirt on Photo Eye(s)  Clean Photo Eye lenses
OR OR
 Bell Hose is damaged  Replace Bell Hose
 Bad poly-flow connection on Pressure Valve  Check for proper operating voltage
 Low air pressure  Confirm that air pressure is between 90 and
120PSI

 Bad toggle switch on Outputs  Toggle output switch to the MANUAL position

Water not  Not programmed properly  Review program
spraying  Tripped motor starter  Reset motor starter
 Failed Pump  Repair or relace pump

Trouble Shooting the DuraBlaster®
There are three main symptoms to troubleshoot for a Belanger® DuraBlaster®:
A. Water is not spraying properly or at all (BOTH Models)

B. The DuraBlaster(s)™ are not rotating properly or at all (Rotating Models ONLY)
C. The DuraBlaster(s)™ are not tracking the tire properly (Rotating Models ONLY).

A. Water is not spraying properly or at all (BOTH Models)
1. Check pump output
YES 1. Check for plugged nozzles relays and fuses
Is any water
spraying? 2. Check for leaks in hoses on 2. Check pump fuse or
DuraBlaster® and in all plumbing
from the pump circuit breaker
3. Troubleshoot pump
NO 3. Check whether the swivels are
worn and leaking using pump
instruction manual
See No Water 4. Verify the pump regulator setting
is Spraying
(Flowchart A1 5. Troubleshoot pump problems
Below) using pump instruction manual

A1. No Water is Spraying (BOTH Models) 1. Verify that pump is
programmed to come
Manually turn NO on for each car
Does the NO pump ON at Does the and/or appropriate

pump run? controller output pump run? wash packages

2. Verify all wires from
YES YES the pump to the
Pump Runs controller
See Pump Runs
(in this flowchart)
