BR-84 Brake system – service brake (air pressure)

e. Remove the ABS controller support's fixing bolts or
nuts and remove the ABS controller and its support
assembly.

f. Remove the ABS controller's fixing bolts on its support
and take away the ABS controller.

7. Installation of ABS controller assembly
a. Install the ABS controller onto the support. Install its
fixing bolts and tighten them.
Torque: 10~12N•m

b. Install the ABS controller and its support assembly on
the cross beam of the instrument panel. Install the
instrument harness support and the fixing nuts and
tighten them.
Torque: 10~12N•m

c. Disconnect the ABS controller connector.

BR-084
