BW - 106 Body - Inner and outer trims

Change
1. Remove the rear inner fender assembly
a. Remove the rear windshield. (refer to Chapter BW body- windshield, window glass- rear windshield,
replacement)
b. Remove left and right B pillar guards. (refer to Chapter BW body- windshield, window glass- interior &
exterior trim –side wall inner shield, replacement)

c. Remove the rear curtain rail mounting screws and remove
the rear window rail.

d. Remove the top cover plastic buckles.

e. Remove the coat hook mounting screws and remove the
coat hooks on both sides.

f. Remove the rear inner fender assembly plastic expansion
screws, and remove the rear inner fender assembly.

2. Install the rear inner fender assembly
a. Install the rear inner fender assembly into the cab, align
the plastic expansion screw mounting holes, and install the
plastic expansion screws.

BW-106
