Body - Dashboard, instrument cluster, ashtray BW - 133

Change IN
1. Remove the glove box assembly
DI
a. Open the glove box cover.
b. Remove the screw pug caps.
EG

TR

AX
c. Remove the glove box assembly mounting bolts and nuts,
and remove the glove box assembly.
FR

ST

BR

BW
2. Remove the deputy dashboard assembly

a. Unscrew the locknut of transmission control mechanism
EL
handle ball and screw off the handle ball assembly.

b. Take off the transmission control rod guard
c. Remove hand brake valve bushing.

BW-133
