EL - 18 Electrical system – electrical components
IN
b. Remove the left front turn signal lamp bulb.
DI
EG
TR
AX
9. Remove the right front turn signal bulb
FR Caution
Follow the same steps as removal of left front turn signal bulb above to remove the right front turn
ST signal bulb.
10. Check the front combination lamp if following failures are present. If yes, repair or adjust or replace
the front combination lamp.
BR
a. Glass burst in the front combination lamp cover.
b. Front lamp internal material is exfoliated (reflector bowl, fluorescent powder).
BW
c. Front combination lamp cover is burnt.
EL d. Water gets into the front combination lamp.
e. Shortcircuit occurs due to the front combination lamp circuit earthing.
f. Poor electrical contact of the front combination lamp circuit exists.
g. The front combination lamp cover glass is discolored.
11. Installing the bulb for the left front turn signal
lamp
a. Mount the bulb of left front turn signal lamp on the
socket.
b. Rotate clockwise to mount the left front turn signal
lamp socket.
EL-018
