EL - 20 Electrical system – electrical components
IN
15. Installing the bulb for the left front high beam lamp
DI a. Install the left front high beam lamp bulb assembly into
place.
EG b. Lock the fixing circlip.
TR
AX
c. Connect the plug & socket connector of the left front high
beam lamp bulb.
FR
ST
BR
BW
d. Install the dust seal cap for the left front high beam lamp
bulb.
EL
16. Installing the bulb for the right front high beam lamp
Caution
Install the right front high beam lamp bulb in the same way as installation of the left front high beam
lamp bulb.
17. Installing the left front combination lamp assembly
a. Install the left front combination lamp assembly into
place. Mount and tighten the fixing bolts for the left front
combination lamp assembly.
EL-020
