EL - 24 Electrical system – electrical components
IN
b. Install the right turn signal lamp assembly into place.
DI Mount and tighten the fixing screws for the right turn signal
lamp.
EG
TR
AX
6. Install the left turn signal lamp assembly.
Caution
FR
Install the left turn signal lamp assembly in the same way as installation of the right turn signal lamp
assembly.
ST
7. Remove the right turn signal lamp bulb
a. Dismount two fixing bolts of right steering lamp
BR
BW
EL
b. Rotate to remove the right turn signal lamp cover.
c. Remove the right turn signal lamp bulb.
EL-024
