P. 1452
EL - 28 Electrical system – electrical components
IN
12. Install the left outline marker lamp bulb
DI a. Install the left outline marker lamp bulb.
EG
TR
AX
b. Position the left outline marker lamp cover, and tighten
the 2 fixing screws.
FR
ST
BR
BW
13. Install the right outline marker lamp bulb
Caution
EL
Install the right outline marker lamp bulb in the same way as the installation of the left outline marker
lamp bulb.
14. Connect the cable of battery negative pole
EL-028
