Electrical system – electrical components EL - 33
IN
Rear combination light
Change DI
1. Dismount the cable of batter negative pole
2. Remove the right rear combination lamp assembly EG
a. Disconnect the plug & socket connector of the right rear
combination lamp harness. TR
AX
FR
b. Remove the fixing nuts for the right rear combination
ST
lamp.
c. Remove the right rear combination lamp assembly.
BR
BW
EL
3. Remove the right rear combination lamp assembly
Caution
Remove the left rear combination lamp assembly in the same way as removal of the right rear
combination lamp assembly.
4. Install the right rear combination lamp assembly
a. Install the right rear combination lamp assembly into
place. Mount and tighten the fixing nut for the right rear
combination lamp assembly.
EL-033
