Electrical system –circuit EL - 215
: Connector between harnesses IN
Number Number Refer to harness (connector position)
DI
Body harness and frame harness (instrument panel
B021 F008
left lower, close to the clutch pedal)
EG
Body harness and frame harness (instrument panel
B023 F003
left lower, close to the clutch pedal)
TR
Frame harness and tail light harness (at back of
F041 H001
frame)
AX
: Grounding
Number Grounding point position Number Grounding point position
FR
H009 Taillight frame harness ground B007 Body left side ground point 1
ST
B005 Front wall left side grounding B069 Front wall right side grounding
