Electrical system –circuit EL - 267

IN

DI

EG

TR

DJ7091Y-2.3-21/7 CZT PP0456701 CZT AX
B004 left front combination lamp B009 to left door harness

Terminal number Color Function
Terminal number Color Function FR
1 Yellow - white
1 Yellow -
2 Red - Yellow Left front dipped headlight
2 Black - Red -
3 Blue - black Left front high beam ST
Earth, left head lamp 3 Blue - orange -
4 White - black
adjusting motor 4 Blue - yellow -
BR
Left high beam adjusting 5 Blue - white -
5 White
motor control signal
6 Blue - black -
power supply, left head
6 Red - Yellow 7 Red - Green - BW
lamp adjusting motor
7 green- black left front turn signal lamp 8 Green - blue -
8 green Left front position lamp 9 - -
EL
9 White - black Earth, left front head lamp
10 Green -

11 Green - black Left front speaker +

12 White - black -

13 - -

14 Green - white -
15 Green - red -
16 - -
17 - -

18 Red - White -
6098-7384 SWS
19 Green - yellow -
B008 to roof harness
20 - -

Terminal number Color Function 21 Red - Blue -
1 Yellow Front dome light power cord
22 Green - yellow Left front speaker -
Signal wire of left front door
2 Green - red
lamp switch
Power cord of left front/right
3 Green
front clearance lamp

4 - -

5 - -
Grounding wire of left front/right
6 White - black
front clearance lamp

EL-267
