EL - 270 Electrical system –circuit
IN
Terminal number Color Function
28 - -
DI
Ignition key not insert
29 Pink
reminder signal
30 - -
EG
31 - -
32 - -
TR
1719059-1 TYCO
AX
B015 combination instrumentB
Terminal number Color Function
FR
1 - -
2 White ABS failure warning signal
ST 3 - -
4 - -
PP0441004 THB
5 - -
BR 6 - - B016 front pressure sensor
7 Yellow - white - Terminal number Color Function
8 Green - red Door open reminder signal
BW
9 - - Power supply, front pressure
1 Red
10 - - sensor
EL 11 Yellow - red Front fog lamp indication
signal 2 Brown Earth, front pressure sensor
12 - -
3 Yellow - black Front pressure sensor signal
Safety belt unfix reminder
13 Blue - white
signal
14 - -
15 Red - Black Coolant level signal
16 - -
17 Red - Yellow Hand brake indication signal
left high beam indication
18 Blue - black
signal
19 - -
20 Yellow - black Speed sensor power supply
power supply, background
PP0441004 THB
21 Green lamp of combination
instrument B017 rear pressure sensor
K wire, combination
22 White Terminal number Color Function
instrument
Power supply, rear pressure
23 Green - red Reverse position indication 1 Red
signal sensor
24 - - 2 Brown Earth, rear pressure sensor
25 - - 3 Purple Rear pressure sensor signal
26 - -
27 - -
EL-270
