Engine section – Engine (Cummins ISF3.8) EG - 53

IN
50. Connect the water supply hose of the engine to the
water pump and install and tighten the clamp
DI

EG

TR

51. Install the heater harness to the inlet pipe and install AX
and tighten the clamp

FR

ST

BR

52. Connect the air inlet piping of the engine to the BW
intake manifold of the engine and install and tighten the
V-clamp
EL

53. Connect the discharging pipe of the engine to the
thermostat and install and tighten the clamp

54. Connect the front exhaust pipe to the turbocharger
and install and tighten the V-clamp

EG-053
