DIAGNOSTICS - ASSEMBLY INSTRUMENT 04-973

(a) Use a multimeter to measure the resistance
between thepin 2 of the brake liquid level
ON
alarm switch A009 and ground.
A009 Standard resistance (check whether there
is short circuit)
1 2
Multimeter connection Standard value 04

A009 (2) - grounding ≤ 2 Ω

ftwxd041317

Check whether the result is normal?
No > Replace the brake liquid level alarm switch.
No> go to step 7

7 . Check the brake liquid level alarm switch
circuit
(a) Disconnect the connector C013 of
combination instrument.

ftwx831083
