34-36 AXLE AND PROPELLER SHAFT - FRONT DRIVING GEAR

(h) Remove the driving gear bearing sleeve.

(i) Remove the driving gear inner bearing inner
ring.

(j) Remove the driving gear spacer.

34

6 . Check the Front Driving Gear
(a) Check for damage and wear on the driving gear surface and repair or replace it if
needed. (Refer to "Chapter 34. Axle & transmission shaft - differential assembly,
overhaul")

NOTICE

Replace the driving and driven gears in pairs. Repair it for minor damage. And replace
it in case of scratch, peeling, corrosion point, crack or overly wear.
(b) Check for wear of the driving gear shaft journal.

Replace a new driving gear in case of severe wear.

7 . Install the Front Driving Gear
